MIL-C-5G
TABLE VIII. Group A inspection.
Inspection
Requirement paragraph
Test Method
Sample
paragraph
procedure
Visual and mechanical examination:
Material
Body dimensions
13 samples
Interface and physical dimensions
0 failures
(other than dimensions)
3.4 to 3.4.4
Marking 1/
3.18 to 3.18.3
Workmanship
Dielectric withstanding voltage
Insulation resistance (at room
ambient temperature)
See 4.5.3.1
Dissipation factor
Capacitance
1/ Marking defects are based on visual examination only. Any subsequent electrical defects shall
not be used as a basis for determining marking defects.
Table IX. Sampling plans for group A electrical inspection.
Lot size
Sample size
2 to
12
100 percent
13 to
150
13
151 to
280
20
281 to
500
29
501 to 1,200
34
1,201 to 3,200
42
3,201 to 10,000
50
10,001 to 35,000
60
35,001 to 150,000
74
150,001 to 500,000
90
500,001 and over
102
4.5.4 Group B inspection. Group B inspection shall consist of the tests specified in table X, in the order shown.
Shipment of capacitor lots shall not be accomplished until representative samples of the lot have successfully
completed the group B tests.
4.5.4.1 Sampling plan. A sample of parts shall be randomly selected in accordance with table X. If one or more
defects are found, the lot shall be rescreened and defects removed. After screening and removal of defects, a new
sample of parts shall be randomly selected in accordance with table X. If one or more defects are found in the
second sample, the lot shall be rejected and shall not be supplied to this specification.
4.5.4.2 Disposition of sample units. Sample units that have been subjected to group B inspection shall not be
delivered on the contract or order.
4.5.5 Retention of qualification. Every 6 months, the manufacturer shall verify the retention of qualification to the
qualifying activity. The supplier shall also notify the qualification activity at any time during the 6-month period that
the inspection data indicates failure of the qualified product to meet the requirements of the specification.
9
