MIL-C-5 Capacitors, Fixed, Mica Dielectric, General Specification ForThis specification covers the general requirements for molded and dipped mica dielectric, fixed capacitors intended primarily for use in high-stability, low-loss radio-frequency applications such as tuned circuits \(see 6.1\). This is a graded specification covering ranges in temperature coefficient, capacitance, tolerance, temperature, and vibration.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13

MIL-C-5G

1.2.1.3 Voltage rating. The voltage rating is identified by a single letter in accordance with table II.

TABLE II. Voltage rating.

Symbol

Voltage rating (volts, dc)

100

300

500

1.2.1.4 Capacitance. The nominal capacitance value expressed in picofarads (pF) is identified by a three-digit

number; the first two digits represent significant figures and the last digit specifies the number of zeros to follow.

1.2.1.5 Capacitance tolerance. The capacitance tolerance is identified by a single letter in accordance with

TABLE III. Capacitance tolerance.

Symbol

Capacitance tolerance

� .5 pF

� 1%

� 2%

� 5%

1.2.1.6 Temperature range. The temperature range is identified by a single letter in accordance with table IV.

TABLE IV. Operating temperature range.

Symbol

Operating temperature range

-55� to +85�C

-55� to +125�C

-55� to +150�C

1.2.1.7 Vibration grade. The only vibration grade still available is grade 3, 10 to 2,000 Hz.

2. APPLICABLE DOCUMENTS

2.1 General. The documents listed in this section are specified in sections 3 and 4 of this specification. This

section does not include documents cited in other sections of this specification or recommended for additional

information or as examples. While every effort has been made to ensure the completeness of this list, document

users are cautioned that they must meet all specified requirements documents cited in sections 3 and 4 of this

specification, whether or not they are listed.

2.2 Government documents.

2.2.1 Specifications. standards. and handbooks. The following specifications, standards, and handbooks form a

part of this document to the extent specified herein. Unless otherwise specified, the issues of these documents are

those cited in the solicitation or contract (See 6.2).

DEPARTMENT OF DEFENSE SPECIFICATIONS

Capacitors, Fixed, Mica Dielectric, Style CM15.

Capacitors, Fixed, Mica Dielectric, Styles CM04, CM05, CM06, CM07, CM08,

CM09, CM10, CM11, CM12, and CM13.

Capacitors, Fixed, Mica Dielectric, Established Reliability and Nonestablished

Reliability, General Specification For.
