MIL-PRF-49464 Capacitors, Chip, Single Layer, Fixed, Parallel Plate, Ceramic Dielectric, Established Reliability, General Specification ForThis specification covers the general requirements for ceramic plate, single layer capacitors. These capacitors are intended for stripline or microstrip applications, usually at frequencies of 1 GHz and higher. Capacitors covered by this specification have failure rate levels \(FRL\) ranging from 1.0 to 0.001 percent per 1,000 hours. These failure rate levels are established at a 90-percent confidence level and maintained at a 10-percent producer\'s risk. They are based on life tests performed at a maximum rated voltage at maximum rated temperature. An acceleration factor of 8:1 has been used to relate life test data obtained at 200 percent of rated voltage at maximum rated temperature, to rated voltage at rated temperature. Statistical Process Control \(SPC\) techniques are required in the manufacturing process to minimize variation in production of capacitors supplied to the requirements of this specification.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12


MIL-PRF-49464C
APPENDIX A
PROCEDURE FOR QUALIFICATION INSPECTION
A.1 SCOPE
A.1.1 Scope. This appendix details the procedure for submission of samples for qualification inspection of
capacitors covered by this specification. This appendix is a mandatory part of the specification. The information
contained herein is intended for compliance. The procedure for extending qualification of the required sample to
other capacitors covered by this specification is also outlined herein.
A.2 APPLICABLE DOCUMENTS. This section is not applicable to this appendix.
A.3 SUBMISSION
A.3.1 Sample.
A.3.1.1 Single-style submission. A sample of the size required in the qualification inspection table, of the largest
case size, highest capacitance value in each voltage rating, in each temperature coefficient limits for which
qualification is sought shall be submitted.
A.4 EXTENT OF QUALIFICATION
A.4.1 Qualification of capacitance range. Capacitance range qualification will be restricted to values equal to and
less than the capacitance value submitted. Capacitance tolerance qualification will be restricted to tolerances equal
to and wider than the tolerance submitted. Voltage rating qualification will be restricted to that submitted.
Temperature coefficient qualification will be limited to that submitted. The PINs in table A-I are the highest
capacitance values in each temperature coefficient and each voltage.
TABLE A-I. Combined submission.
Rated
Style
PIN 1/
Number of units 2/
voltage
CPCR01
M49464F01100JAKAHM
67
16
CPCR01
M49464F019R1BBKAHM
67
25
CPCR01
M49464F016R2BCKAHM
67
50
CPCR01
M49464F013R0BDKAHM
67
100
CPCR01
M49464G01360JAKAHM
67
16
CPCR01
M49464G01300JBKAHM
67
25
CPCR01
M49464G01200JCKAHM
67
50
CPCR01
M49464G01100JDKAHM
67
100
CPCR01
M49464W01102KAKAHM
67
16
CPCR01
M49464W01681KBKAHM
67
25
CPCR01
M49464W01621KCKAHM
67
50
CPCR01
M49464W01301KDKAHM
67
100
1/ 61 units will be submitted for qualification if certification is given for fungus resistance.
18
