MIL-PRF-49137E
TABLE I. Voltage.
Rated (+85°C)
Surge (+85°C)
Symbol
Volts, dc
Volts, dc
A
2
2.6
B
3
4.0
C
4
5.0
D
6
8.0
F
10
13.0
H
15
20.0
J
20
26.0
K
25
32.0
M
35
46.0
N
50
65.0
1.2.1.4 Capacitance tolerance. The capacitance tolerance is identified by a single letter as shown in table II.
TABLE II. Capacitance tolerance.
Capacitance tolerance (±)
Symbol
K
10 percent
M
20 percent
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3 and 4 of this specification. This
section does not include documents cited in other sections of this specification or recommended for additional
information or as examples. While every effort has been made to ensure the completeness of this list, document
users are cautioned that they must meet all specified requirements documents cited in sections 3 and 4 of this
specification, whether or not they are listed.
2.2 Government documents.
2.2.1 Specifications, standards, and handbooks. The following specifications, standards, and handbooks form a
part of this document to the extent specified herein. Unless otherwise specified, the issues of these documents are
those cited in the solicitation or contract (see 6.2).
DEPARTMENT OF DEFENSE SPECIFICATIONS
-
Capacitors, Fixed, Electrolytic (Solid Electrolyte), Tantalum, Polar, Molded,
Nonhermetically Sealed, Style CX01
-
Capacitors, Fixed, Electrolytic (Solid Electrolyte), Tantalum, Polar,
Conformal Coated, Nonhermetically Sealed, Styles CX02 and CX12
-
Capacitors, Fixed, Electrolytic (Solid Electrolyte), Tantalum, Polar, Molded,
Nonhermetically Sealed, Style CX05
-
Capacitors, Fixed, Electrolytic (Solid Electrolyte), Tantalum, Polar,
Nonhermetically Sealed, Styles CX06 and CX16
2
