MIL-PRF-39001E
TABLE I. Characteristic.
Symbol
Temperature coefficient
Capacitance drift
Parts/million/C (ppm/°C)
C
-200 to +200
± (0.5 percent + 0.1 picofarad (pF))
E
-20 to +100
± (0.1 percent + 0.1 pF)
F
-0 to +70
± (0.05 percent + 0.1 pF)
1.2.1.3 Capacitance. The nominal capacitance value expressed in pF is identified by a three-digit number; the
first two digits represent significant figures and the last digit specifies the number of zeros to follow. When the
nominal value is less than 10 pF, the letter R is used to indicate the decimal point and the succeeding digit(s) of the
group represent significant figure(s). For example 1R0 indicates 1.0 pF; R75 indicates 0.75 pF; and 0R5 indicates
0.5 pF.
1.2.1.4 Capacitance tolerance. The capacitance tolerance in percent or pF, as applicable, is identified by a single
letter in accordance with table II.
TABLE II. Capacitance tolerance.
Symbol
Capacitance tolerance
±0.5 pF
D
±1 percent
F
±2 percent
G
±5 percent
J
1.2.1.5 Operating temperature range. The operating temperature range is identified by a single letter in
accordance with table III.
TABLE III. Operating temperature range.
Operating temperature range, C
Symbol
O
-55 to +125
P
-55 to +150
1.2.1.6 Rated voltage. The rated voltage is identified by a single letter in accordance with table IV.
TABLE IV. Rated voltage.
Symbol
DC rated voltage, volts
A
100
C
300
D
500
Y
50
1.2.1.7 Product level designator. The FRL in percent per 1,000 hours is identified by a single letter in accordance
with table V and is based on rated voltage at 125C or 150C, as applicable.
TABLE V. Product level designator.
Symbol
Product level designator
C
----
M
1.0 percent per 1,000 hours
P
0.1 percent per 1,000 hours
R
0.01 percent per 1,000 hours
S
0.001 percent per 1,000 hours
2
