MIL-DTL-3965 Capacitor, Fixed Electrolytic \(Nonsolid Electrolyte\), TantalumThis specification covers the general requirements for tantalum, electrolytic \(nonsolid electrolyte\), fixed capacitors \(polarized and nonpolarized\), hermetically and nonhermetically sealed \(see 1.2.1.7\) in metal cases; style CL67 and all tubular-foil styles are insulated \(see 6.1\). This specification also covers removable counting brackets for use with the CL55-series capacitors.

Pages 1 - - 26 - 27 - 28 - 29 - 30 - 31 - 32 - 33 - 34 - 35 - 36 - 37 - 38 - 39|||


MIL-DTL-3965H
APPENDIX A
TABLE XIII. Voltage group submittal data - Continued.
Style
Type designation
Sample size
Rated voltage
CL55BE242MPG
14
15
CL55
CL55BQ181MPG
14
150
CL66BB331JPG
20
6
CL66
CL66BE171JPG
20
15
(Low-capacitance
CL66BH101JPG
20
30
series)
CL66BL400JPG
20
75
CL66BN300JPG
20
100
CL66BP090JPG
20
125
CL66BB561JPG
20
6
CL66BE271JPG
CL66
20
15
CL66BG181JPG
(High-capacitance
20
25
series) 1/
CL66BL560JPG
20
75
CL66BN430JPG
20
100
CL66BP250JPG
20
125
CL67BB331JPG
20
6
CL67
CL67BE171JPG
20
15
(Low-capacitance
CL67BH101JPG
20
30
series)
CL67BL400JPG
20
75
CL67BN300JPG
20
100
CL67BP090JPG
20
125
CL67BB561JPG
20
6
CL67
CL67BE271JPG
20
15
(High-capacitance
CL67BG181JPG
20
25
series)
CL67BL560JPG
20
75
CL67BN430JPG
20
100
CL67BP250JPG
20
125
1/ Qualification of the high-capacitance series may be the basis for qualification of the low-
capacitance series of the same voltage group.
