MIL-DTL-3965H
APPENDIX A
A3.1.3 Combined-style type. The following details apply:
a.
Sample size: As specified in table XIV.
b.
Sampling criteria: Sample units of (1) the same seal, voltage group, and electrolyte, and (2) the combination
of styles as specified in table XIV; one style of the highest capacitance value for the lowest rated voltage
(see NOTE in A3.1.2b), and the other style of the highest capacitance value for the highest rated voltage
within a single voltage group.
c.
Limits of coverage: As specified in A3.2.1c, except that coverage will be extended to both styles.
TABLE XIII. Voltage group submittal data.
Rated voltage
Sample
Style
Type
size
designation
CL10
CL10BC141TPG
20
8
CL10BM160TPG
20
90
CL10BR080TPG
20
180
CL10BT040TPG
20
360
CL13
CL13BC141TPG
20
8
CL13BM160TPG
20
90
CL13BR080TPG
20
180
CL13BT040TPG
20
360
CL14
CL14BF201UPG
14
20
CL14BM500UPG
14
90
CL14BR250UPG
14
180
CL14BT120UPG
14
360
CL14BU100UPG
14
450
CL14BW070UPG
14
630
CL16
CL16BF201UPG
14
20
CL16BM500UPG
14
90
CL16BR250UPG
14
180
CL16BT120UPG
14
360
CL16BU100UPG
14
450
CL16BW070UPG
14
640
CL17
CL17BH132MPG
14
30
CL17BM451MPG
14
90
CL17BR231MPG
14
180
CL17BT300MPG
14
360
CL17BU250MPG
14
450
CL17BW180MPG
14
630
CL18
CL18BH132MPG
14
30
CL18BM451MPG
14
90
CL18BR231MPG
14
180
CL18BT300MPG
14
360
CL18BU250MPG
14
450
CL18BW180MPG
14
630
34
