MIL-C-25F
APPENDIX A
Circuit tested
Circuits also represented
2
1
1, 2, 6
4
1, 2, 4, 6
5
1, 2
6
b. Any capacitance tolerance may also represent all other available capacitance tolerances.
c. Any one of styles CP53, CP54, or CP55 may also represent the other two of these styles.
d. The specimens to which qualification is extended shall be of the same basic design and shall utilize the same
materials, finish, impregnant or filling compound as the qualified specimens.
e. Watt-second group IB may represent watt-second group IA. The watt-second-range of qualification shall be
in accordance with table A-III.
f. For style group D (see table A-I), capacitor type CP55B5-G254-1 may represent all types; however,
submission in accordance with the other provisions of this procedure is preferred.
TABLE A-III. Watt-second range of qualification.
Watt-second group of the
Range of qualification
submission
All watt-second ratings up to 120 percent of that of the
I
0 to 0.5 watt-seconds
submission.
All watt-second ratings up to 120 percent of that of
II 0.5 to 5 watt-seconds
that of the submission but ≥ 0.40 watt-second.
All watt-second ratings up to 120 percent of that of the
III 5 to 50 watt-seconds
submission but ≥ 4.0 watt-seconds.
All watt-second ratings up to 120 percent of that of the
IV 50 watt-seconds and greater
submission but ≥ 40 watt-seconds.
