MIL-PRF-87164 Capacitors, Fixed, Mica Dielectric, High Reliability, General Specification For \(See Notice 1 For Replacement Information\)This specification covers the general requirements for high reliability, mica dielectric, fixed capacitors for space, missile, and other high reliability applications. Capacitors covered by this specification may be used in critical applications where the utmost in stability and dependability is required and where variations in capacitance with respect to temperature, voltage, frequency, and life cannot be tolerated \(see 6.1\). An acceleration factor of 25:1 has been used to relate life test data obtained at 150 percent of rated voltage at rated temperature to rated voltage at rated temperature.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11

MIL-PRF-87164A

1.2.1.3 Voltage. The rated voltage for continuous operation at +125�C is identified by a single letter as shown in

table II.

TABLE II. Rated voltage.

Symbol

Rated voltage (Volts, dc)

100

300

500

1.2.1.4 Capacitance. The nominal capacitance value, expressed in picofarads (pF) is identified by a three-digit

number; the first two digits represent significant figures and the last digit specifies the number of zeros to follow.

When the nominal value is less than 10 pF, the letter "R" shall be used to indicate the decimal point and the

succeeding digit shall represent a significant figure. For example, 1R0 indicates 1.0 pF.

1.2.1.5 Capacitance tolerance. The capacitance tolerance is identified by a single letter in accordance with table

III.

TABLE III. Capacitance tolerance.

Symbol

Capacitance tolerance

�0.5 pF

�1 percent

�2 percent

�5 percent

2. APPLICABLE DOCUMENTS

2.1 General. The documents listed in this section are specified in sections 3 and 4 of this specification. This

section does not include documents cited in other sections of this specification or recommended for additional

information or as examples. While every effort has been made to ensure the completeness of this list, document

users are cautioned that they must meet all specified requirements documents cited in sections 3 and 4 of this

specification, whether or not they are listed.

2.2 Government documents.

2.2.1 Specifications, standards, and handbooks. The following specifications, standards, and handbooks form a

part of this document to the extent specified herein. Unless otherwise specified, the issues of these documents are

those listed in the issue of the Department of Defense Index of Specifications and Standards (DoDISS) and

supplement thereto, cited in the solicitation (see 6.2).

SPECIFICATIONS

DEPARTMENT OF DEFENSE

MIL-PRF-39001/5

Capacitors, Fixed, Mica Dielectric, Established Reliability; Styles CMR03,

CMR04, CMR05, CMR06, CMR07, and CMR08.

MIL-PRF-87164/1

Capacitors, Fixed MICA Dielectric, High Reliability, Style CMS04.

MIL-PRF-87164/2

Capacitors, Fixed MICA Dielectric, High Reliability, Style CMS05.

MIL-PRF-87164/3

Capacitors, Fixed MICA Dielectric, High Reliability, Style CMS06.

MIL-PRF-87164/4

Capacitors, Fixed MICA Dielectric, High Reliability, Style CMS07.

MIL-PRF-87164/5

Capacitors, Fixed MICA Dielectric, High Reliability, Style CMS03.
