MIL-PRF-49137E
APPENDIX A
PROCEDURE FOR QUALIFICATION INSPECTION
A.1. SCOPE
A.1.1 Scope. This appendix details the procedure for submission of samples for qualification inspection of
capacitors covered by this specification. The procedure for extending qualification of the required sample to other
capacitors covered by this specification is also outlined herein. This appendix is a mandatory part of the
specification. The information contained herein is intended for compliance.
A.2 APPLICABLE DOCUMENTS. This section is not applicable to this appendix.
A.3. SUBMlSSlON
A.3.1 Sample.
A.3.1.1 Single-style submission. A sample consisting of 154 (160 for metal-cased units) units of the highest
capacitance value in each voltage rating in each style for which qualification is sought shall be submitted.
A.3.1.2 Combined-voltage submission. A sample consisting of sample units of the highest capacitance value in
each voltage group in each style for which qualification is sought shall be submitted (see table A-I).
APPENDIX A
TABLE A-I. Combined voltage submission.
Style
Type designation
Number of units
Rated volts
CX01D686-
77
6
CX01
CX01J186-
77
20
CX01K126-
77
25
CX01N565-
77
50
CX02D337-
77
6
CX02
CX02J107-
77
20
CX02K686-
77
25
CX02N226-
77
50
CX05D476-
77
6
CX05
CX05J156-
77
20
CX05K106-
77
25
CX05N475-
77
50
CX06A106-
77
2
CX06
CX06F107-
77
10
CX06H686-
77
15
CX06M226-
77
35
CX12D686-
77
6
CX12
CX12J156-
77
20
CX12K106-
77
25
CX12N475-
77
50
CX16A106-
77
2
CX16
CX16F107-
77
10
CX16H686-
77
15
CX16M226-
77
35
18
