MIL-PRF-39006/21C
Dimensions
Basic case
Insulated case
Case
E
L 1/
D
D
±.250 (6.35)
size
+.031 (0.79)
max
±.016 (0.41)
-.016 (0.41)
T1
.453 (11.51)
.188 (4.78)
.219 ( 5.56)
1.500 (38.10)
T2
.641 (16.28)
.281 (7.14)
.312 ( 7.92)
2.250 (57.15)
T3
.766 (19.46)
.375 (9.53)
.406 (10.31)
2.250 (57.15)
T4
1.062 (26.97) 2/
.375 (9.53)
.406 (10.31)
2.250 (57.15)
1/ Length of basic case; sleeving shall be as specified in MIL-PRF-39006.
2/ For the T4 case size only, the negative L dimension tolerance is -.023 (0.58).
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are in parentheses.
3. Metric equivalents (to the nearest 0.01 mm) are given for general information only and are based
upon 1 inch = 25.4 mm.
4. The weld shall not be enclosed in the end seal.
FIGURE 1. Style CLR69 capacitors - Continued.
2
