MIL-PRF-14409J
TABLE I. Characteristic.
Temperature coefficient
Operating
referred to an ambient
temperature
Symbol
Capacitance drift
temperature of +25°C
range (°C)
(Parts/million/°C)
G
-55 to +125
±150
±.5 percent maximum rated value
±.2 percent of maximum rated value or .04 pF
H
-55 to +125
±100
(whichever is greater)
±.15 percent of maximum rated value or .02 pF
J
-55 to +125
±50
(whichever is greater)
±.18 percent of maximum rated value or .03 pF
0 ± 75
K
-55 to +125
(whichever is greater)
±.1 percent of maximum rated value or .01 pF
Q
-55 to +150
+50, -0
(whichever is greater)
±.1 percent of maximum rated value or .01 pF
T
-65 to +125
±20
(whichever is greater)
±.1 percent of maximum rated value or .01 pF
L
-55 to +125
50 ±50
(whichever is greater)
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3 and 4 of this specification. This
section does not include documents cited in other sections of this specification or recommended for additional
information or as examples. While every effort has been made to ensure the completeness of this list, document
users are cautioned that they must meet all specified requirements documents cited in sections 3 and 4 of this
specification, whether or not they are listed.
2.2 Government documents.
2.2.1 Specifications, standards, and handbooks. The following specifications, standards, and handbooks form a
part of this document to the extent specified herein. Unless otherwise specified, the issues of these documents are
those cited in the solicitation or contract.
FEDERAL STANDARDS
-
Screw-Thread Standards for Federal Services
DEPARTMENT OF DEFENSE SPECIFICATONS
(See supplement 1 for a full list of associated specification sheets)
DEPARTMENT OF DEFENSE STANDARDS
-
Test Method Standard Electronic and Electrical Component Parts
-
Marking of Electrical and Electronic Parts
(Copies of these documents are available online at https://quicksearch.dla.mil/ or from the Standardization
Document Order Desk, 700 Robbins Avenue, Building 4D, Philadelphia, PA 19111-5094.)
2
