MIL-DTL-3965H
1.2.1.6 Construction. Construction is identified by a single letter as shown in table III.
TABLE III. Construction.
Symbol
Construction
P
Polarized
1.2.1.7 Type of seal. Type of seal is identified by a single letter as shown in table IV.
TABLE IV. Type of seal.
Symbol
Type of seal
G
Hermetic (glass-to-metal)
1.2.2 Type designation of removable mounting brackets. Type designation of removable mounting brackets will be
in the following form, and as specified (see 3.1 and 6.2):
CL050
F
C1
Bracket
Design
Bracket size
Designator
(1.2.2.2)
(1.2.2.3)
(1.2.2.1)
1.2.2.1 Bracket designator. Bracket designator is identified by the two-letter symbol "CL" followed by a three-digit
number. The number consists of a zero, followed by two digits applicable to the particular capacitor-case series for
which the bracket is intended. For example: CL050 brackets will be used for capacitor style CL55.
1.2.2.2 Design. The bracket design is identified by a single letter "F" for footed bracket and "S" for spade-lug
bracket.
1.2.2.3 Bracket size. The bracket size corresponds to the capacitor-case size (see 3.1).
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3 and 4 of this specification. This
section does not include documents cited in other sections of this specification or recommended for additional
information or as examples. While every effort has been made to insure the completeness of this list, document
users are cautioned that they must meet all specified requirements of the documents cited in sections 3 and 4 of this
specification, whether or not they are listed.
3
