MIL-DTL-3965H
1.2.1.3 Rated voltage. The rated voltage is identified by a single letter as shown in table I.
TABLE I. Rated voltage.
Symbol
Rated voltage
Symbol
Rated voltage
(-55°C to +85°C)
(-55°C to +85°C)
Volts, dc
Volts, dc
3
100
A
N
6
250
B
O
8
125
C
P
10
150
D
Q
E
15
180
R
F
20
270
S
G
25
360
T
H
30
450
U
112
540
I
V
50
630
J
W
60
300
K
X
75
375
L
Y
90
200
M
Z
1.2.1.4 Capacitance. The nominal capacitance value, expressed in microfarad (µF), is identified by a three-digit
number; the first two digits represent significant figures and the last digit specifies the number of zeros to follow.
When the nominal capacitance is less than 10 and does not involve fractional values, the first digit will be a zero.
When fractional values of a µF, are required, the letter "R" will be used to indicate the decimal point and will be
placed where appropriate in the three-digit number. For example: 2R5 represents 2.5 µF, R8 represents 0.8 µF; and
R35 represents 0.35 µF.
1.2.1.5 Capacitance tolerance. The capacitance tolerance is identified by a single letter as shown in table II.
TABLE II. Capacitance tolerance.
Symbol
Capacitance
tolerance
Percent
±5
J
±10
K
±15
L
M
±20
S
+30, -15
T
+50, -15
U
+75, -15
2
