MIL-PRF-83500A
TABLE I. Qualification inspection.
Number of
Examination or test
Requirement
Test
Number of
failures
paragraph
paragraph
sample
permitted
units to be
inspected 1/
2/
Group I
Visual and mechanical examination (internal)
Materials, design, construction, and
workmanship - - - - - - - - - - - - - - - - - - - - - - - -
3.1, 3.3, 3.4,
4.6.1
2
0
and 3.31
Visual and mechanical examination (external)
Physical dimensions, materials, markings 4/
And workmanship - - - - - - - - - - - - - - - - - - - - -
3.1, 3.3, 3.29,
4.6.1
and 3.31
Burn-in 3/ - - - - - - - - - - - - - - - - - - - - - - - - - - - -
3.5
4.6.2
DC leakage 3/ - - - - - - - - - - - - - - - - - - - - - - - - -
3.6
4.6.3
70
1
Capacitance 3./ - - - - - - - - - - - - - - - - - - - - - - - -
3.7
4.6.4
Dissipation factor 3/ - - - - - - - - - - - - - - - - - - - - -
3.8
4.6.5
Group II
Shock (specified pulse) - - - - - - - - - - - - - - - - - - -
3.9
4.6.6
Vibration, high frequency - - - - - - - - - - - - - - - - - -
3.10
4.6.7
6
1
Thermal shock - - - - - - - - - - - - - - - - - - - - - - - - -
3.11
4.6.8
Salt atmosphere - - - - - - - - - - - - - - - - - - - - - - - -
3.12
4.6.9
Group III
Solderability (capacitors with radial pin
terminals and terminal tabs only) - - - - - - - - - -
3.13
4.6.10
2
Terminal strength - - - - - - - - - - - - - - - - - - - - - - -
3.14
4.6.11
Surge voltage - - - - - - - - - - - - - - - - - - - - - - - - - -
3.15
4.6.12
6
1
Moisture resistance - - - - - - - - - - - - - - - - - - - - - -
3.16
4.6.13
Low temperature (storage) - - - - - - - - - - - - - - - - -
3.17
4.6.14
Seal - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
3.18
4.6.15
Group IV
Stability at low and high temperatures - - - - - - - - -
3.19
4.6.16
Barometric pressure (reduced) - - - - - - - - - - - - - -
3.20
4.6.17
6
1
Reverse voltage (applicable to polarized
capacitors only) - - - - - - - - - - - - - - - - - - - - - -
3.21
4.6.18
Group V
Life at 85°C (2,000 hour) - - - - - - - - - - - - - - - - - -
3.22.1
4.6.19.1
12
1
Life at 125°C (2,000-hour) - - - - - - - - - - - - - - - - -
3.23
4.6.20
6
See footnotes at end of table.
9
