MIL-PRF-55365H

3.26 Marking. Molded style capacitors shall be marked in accordance with method I of MIL-STD-1285, and shall

be as specified (see 3.1). Polarity marking shall be as specified (see 3.1). All styles shall have the following

information marked on the package.

a. "JAN" brand.

b. PIN.

c. Manufacturer's source code in accordance with MIL-STD-1285.

d. Lot date code.

e. Optional marking of lot identification number on individual capacitors.

3.26.1 "JAN" and "J" marking. The United Stated Government has adopted, and is exercising legitimate control

over the certification marks "JAN" and "J", respectively, to indicate that items so marked or identified are

manufactured to, and meet all the requirements of specifications. Accordingly, items acquired to, and meeting all of

the criteria specified herein and in applicable specifications shall bear the certification mark "JAN" except that items

too small to bear to certification mark "JAN" shall bear the letter "J". The "JAN" or "J" shall be placed immediately

before the part number except that if such location would place hardship on the manufacturer in connection with such

marking, the "JAN" or "J" may be located on the first line above or below the part number. Items furnished under

contracts or orders which either permit or require deviation from the conditions or requirements specified herein or in

applicable specifications shall not bear "JAN" or "J". In the event an item fails to meet the requirements of the

specification and the applicable specification sheets or associated specifications, the manufacturer shall remove

completely the military part number and the "JAN" or the "J" from the sample tested and also from all items

represented by the sample. The "JAN" or ""J" certification mark shall not be used on products acquired to contractor

drawings or specifications. The United States Government has obtained Certificate of Registration Number 504,860

for the certification mark "JAN" and Registration Number 1,586,261 for the certification mark "J".

3.26.2 Substitution of FRL and product levels. The manufacturer may substitute, with acquiring agency approval,

FRL and product levels in accordance with table V. If a manufacturer only utilizes Weibull grading, then product

manufactured to Weibull product levels B, C, or D may be marked as Exponential product levels M, P, R, or S and

supplied on the order.

TABLE V. FRL and product level substitutability.

May be substituted for

Parts qualified to

FRL

FRL product level

A, M, P, R, S, B, and C

A, M, P, R, S, and B

A, M, P, R, and S

A, M, P, and R

A, M, and P

A and M
