MIL-PRF-39022-10 Capacitors, Fixed, Metallized, Paper-Plastic Film Dielectric, Direct Current \(Hermetically Sealed In Metal Cases\) Established Reliability, Style Chr10 \(Insulated\)

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12


. . .
MIL-PRF-39022/10B
TABLE I. Capacitor characteristics and dimensions. ­ Continued.
Part or Identifying
DC rated
Capacitance
Dimensions, nominal 3/ 4/ 5/
value in μF
L ±.031
Number (PIN) 1/
voltage
D +.015, -.005
M39022/10-205--
300
2.0
.750
2.312
M39022/10-225--
300
2.2
1.000
1.812
M39022/10-255--
300
2.5
1.000
1.812
M39022/10-275--
300
2.7
1.000
1.812
M39022/10-305--
300
3.0
1.000
2.062
M39022/10-335--
300
3.3
1.000
2.312
M39022/10-395--
300
3.9
1.000
2.562
M39022/10-103--
400
.01
.235
.688
M39022/10-123--
400
.012
.235
.812
M39022/10-153--
400
.015
.235
.812
M39022/10-183--
400
.018
.235
.812
M39022/10-223--
400
.022
.312
.688
M39022/10-273--
400
.027
.312
.812
M39022/10-333--
400
.033
.312
.812
M39022/10-393--
400
.039
.312
.938
M39022/10-473--
400
.047
.400
.812
M39022/10-563--
400
.056
.400
.812
M39022/10-683--
400
.068
.400
.938
M39022/10-823--
400
.082
.400
.938
M39022/10-104--
400
.10
.400
1.125
M39022/10-124--
400
.12
.400
1.312
M39022/10-154--
400
.15
.400
1.312
M39022/10-184--
400
.18
.562
1.125
M39022/10-224--
400
.22
.562
1.125
M39022/10-274--
400
.27
.562
1.312
M39022/10-334--
400
.33
.562
1.562
M39022/10-394--
400
.39
.562
1.562
M39022/10-474--
400
.47
.562
1.812
M39022/10-564--
400
.56
.670
1.562
M39022/10-684--
400
.68
.670
1.812
M39022/10-824--
400
.82
.750
1.812
M39022/10-105--
400
1.0
.750
2.062
M39022/10-125--
400
1.2
1.000
1.812
M39022/10-155--
400
1.5
1.000
1.812
M39022/10-185--
400
1.8
1.000
2.062
M39022/10-205--
400
2.0
1.000
2.062
M39022/10-225--
400
2.2
1.000
2.312
M39022/10-255--
400
2.5
1.000
2.562
M39022/10-275--
400
2.7
1.000
2.562
M39022/10-103--
600
.01
.312
.812
M39022/10-123--
600
.012
.312
.812
M39022/10-153--
600
.015
.400
.812
M39022/10-183--
600
.018
.400
.812
M39022/10-223--
600
.022
.400
.812
M39022/10-273--
600
.027
.400
.937
M39022/10-333--
600
.033
.400
.937
M39022/10-393--
600
.039
.400
1.125
M39022/10-473--
600
.047
.400
1.125
M39022/10-563--
600
.056
.400
1.312
M39022/10-683--
600
.068
.400
1.312
6
