MIL-PRF-39022-10 Capacitors, Fixed, Metallized, Paper-Plastic Film Dielectric, Direct Current \(Hermetically Sealed In Metal Cases\) Established Reliability, Style Chr10 \(Insulated\)

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12


. . . .
MIL-PRF-39022/10B
TABLE I. Capacitor characteristics and dimensions. ­ Continued.
Part or Identifying
DC rated
Capacitance
Dimensions, nominal 3/ 4/ 5/
value in μF
L ±.031
Number (PIN) 1/
voltage
D +.015, -.005
M39022/10-394--
200
.39
.400
.938
M39022/10-474--
200
.47
.400
1.125
M39022/10-564--
200
.56
.400
1.312
M39022/10-684--
200
.68
.500
1.125
M39022/10-824--
200
.82
.500
1.125
M39022/10-105--
200
1.0
.562
1.125
M39022/10-125--
200
1.2
.562
1.312
M39022/10-155--
200
1.5
.562
1.312
M39022/10-185--
200
1.8
.562
1.812
M39022/10-205--
200
2.0
.562
1.812
M39022/10-225--
200
2.2
.562
1.812
M39022/10-275--
200
2.7
.670
1.562
M39022/10-305--
200
3.0
.750
1.562
M39022/10-335--
200
3.3
.750
1.812
M39022/10-405--
200
4.0
.750
1.812
M39022/10-475--
200
4.7
.750
2.062
M39022/10-505--
200
5.0
.750
2.062
M39022/10-565--
200
5.6
.750
2.312
M39022/10-605--
200
6.0
.750
2.312
M39022/10-705--
200
7.0
1.000
1.812
M39022/10-825--
200
8.2
1.000 2/
2.062
M39022/10-106--
200
10.0
1.000 2/
2.312
M39022/10-103--
300
.01
.193
.688
M39022/10-123--
300
.012
.235
.688
M39022/10-153--
300
.015
.235
.688
M39022/10-183--
300
.018
.235
.812
M39022/10-223--
300
.022
.235
.812
M39022/10-273--
300
.027
.312
.688
M39022/10-333--
300
.033
.312
.688
M39022/10-393--
300
.039
.312
.812
M39022/10-473--
300
.047
.312
.812
M39022/10-563--
300
.056
.312
.938
M39022/10-683--
300
.068
.312
.938
M39022/10-823--
300
.082
.400
.812
M39022/10-104--
300
.10
.400
.938
M39022/10-124--
300
.12
.400
.938
M39022/10-154--
300
.15
.400
1.125
M39022/10-184--
300
.18
.400
1.312
M39022/10-224--
300
.22
.400
1.312
M39022/10-274--
300
.27
.562
1.125
M39022/10-334--
300
.33
.562
1.125
M39022/10-394--
300
.39
.562
1.125
M39022/10-474--
300
.47
.562
1.562
M39022/10-564--
300
.56
.562
1.562
M39022/10-684--
300
.68
.670
1.312
M39022/10-824--
300
.82
.670
1.562
M39022/10-105--
300
1.0
.670
1.812
M39022/10-125--
300
1.2
.670
1.812
M39022/10-155--
300
1.5
.750
2.062
M39022/10-185--
300
1.8
.750
2.062
