MIL-PRF-39022-10 Capacitors, Fixed, Metallized, Paper-Plastic Film Dielectric, Direct Current \(Hermetically Sealed In Metal Cases\) Established Reliability, Style Chr10 \(Insulated\)

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12


. . . .
MIL-PRF-39022/10B
TABLE I. Capacitor characteristics and dimensions. ­ Continued.
Part or Identifying
DC rated
Capacitance
Dimensions, nominal 3/ 4/ 5/
value in μF
L ±.031
Number (PIN) 1/
voltage
D +.015, -.005
M39022/10-154--
100
.15
.312
.625
M39022/10-184--
100
.18
.312
.625
M39022/10-224--
100
.22
.312
.688
M39022/10-274--
100
.27
.312
.688
M39022/10-334--
100
.33
.312
.812
M39022/10-394--
100
.39
.312
.812
M39022/10-474--
100
.47
.400
.688
M39022/10-564--
100
.56
.400
.812
M39022/10-684--
100
.68
.400
.812
M39022/10-824--
100
.82
.400
.938
M39022/10-105--
100
1.0
.400
.938
M39022/10-125--
100
1.2
.500
.938
M39022/10-155--
100
1.5
.500
.938
M39022/10-185--
100
1.8
.500
1.125
M39022/10-205--
100
2.0
.500
1.125
M39022/10-225--
100
2.2
.500
1.125
M39022/10-275--
100
2.7
.562
1.312
M39022/10-305--
100
3.0
.562
1.312
M39022/10-335--
100
3.3
.562
1.312
M39022/10-405--
100
4.0
.562
1.562
M39022/10-475--
100
4.7
.670
1.312
M39022/10-505--
100
5.0
.670
1.312
M39022/10-565--
100
5.6
.670
1.312
M39022/10-685--
100
6.8
.670
1.562
M39022/10-825--
100
8.2
.670
1.812
M39022/10-106--
100
10.0
.750
1.812
M39022/10-126--
100
12.0
.750
1.812
M39022/10-156--
100
15.0
1.000 2/
1.875
M39022/10-186--
100
18.0
1.000 2/
1.875
M39022/10-206--
100
20.0
1.000 2/
1.875
M39022/10-226--
100
22.0
1.000 2/
1.875
M39022/10-103--
200
.01
.174
.625
M39022/10-123--
200
.012
.174
.625
M39022/10-153--
200
.015
.174
.625
M39022/10-183--
200
.018
.193
.625
M39022/10-223--
200
.022
.193
.625
M39022/10-273--
200
.027
.235
.625
M39022/10-333--
200
.033
.235
.625
M39022/10-393--
200
.039
.235
.688
M39022/10-473--
200
.047
.235
.688
M39022/10-563--
200
.056
.312
.625
M39022/10-683--
200
.068
.312
.625
M39022/10-823--
200
.082
.312
.688
M39022/10-104--
200
.10
.312
.688
M39022/10-124--
200
.12
.312
.812
M39022/10-154--
200
.15
.312
.812
M39022/10-184--
200
.18
.400
.688
M39022/10-224--
200
.22
.400
.812
M39022/10-274--
200
.27
.400
.812
M39022/10-334--
200
.33
.400
.938
4
