MIL-PRF-39014/22F
TABLE III. Dash numbers and electrical characteristics - Continued.
Dash number
DC
Capaci-
Capaci-
Failure rate level (%/1,000 hours)
rated
tance
tance
voltage
Standard lead length 1/
Optional longer lead length 1/
tolerance
(pF)
(volts)
1.0(M)
0.1(P)
0.01(R)
0.001(S)
1.0(M)
0.1(P)
0.01(R)
0.001(S)
Style CKR22, Characteristic BX (voltage-temperature limits of ±15% and +15, -25%) - Continued.
0176
0476
0776
1076
3176
3476
3776
4076
10,000
K
100
0177
0477
0777
1077
3177
3477
3777
4077
10,000
M
100
0178
0478
0778
1078
3178
3478
3778
4078
12,000
K
50
0179
0479
0779
1079
3179
3479
3779
4079
15,000
K
50
0180
0480
0780
1080
3180
3480
3780
4080
15,000
M
50
0181
0481
0781
1081
3181
3481
3781
4081
18,000
K
50
0182
0482
0782
1082
3182
3482
3782
4082
22,000
K
50
0183
0483
0783
1083
3183
3483
3783
4083
22,000
M
50
0184
0484
0784
1084
3184
3484
3784
4084
27,000
K
50
0185
0485
0785
1085
3185
3485
3785
4085
33,000
K
50
0186
0486
0786
1086
3186
3486
3786
4086
33,000
M
50
0187
0487
0787
1087
3187
3487
3787
4087
39,000
K
50
0188
0488
0788
1088
3188
3488
3788
4088
47,000
K
50
0189
0489
0789
1089
3189
3489
3789
4089
47,000
M
50
0190
0490
0790
1090
3190
3490
3790
4090
56,000
K
50
0191
0491
0791
1091
3191
3491
3791
4091
68,000
K
50
0192
0492
0792
1092
3192
3492
3792
4092
68,000
M
50
0193
0493
0793
1093
3193
3493
3793
4093
82,000
K
50
0194
0494
0794
1094
3194
3494
3794
4094
100,000
K
50
0195
0495
0795
1095
3195
3495
3795
4095
100,000
M
50
Style CKR23, Characteristic CG (voltage-temperature limits of 0 ±30 ppm/°C)
0258
0558
0858
1158
3258
3558
3858
4158
560
F
200
0259
0559
0859
1159
3259
3559
3859
4159
560
J
200
0260
0560
0860
1160
3260
3560
3860
4160
560
K
200
0261
0561
0861
1161
3261
3561
3861
4161
680
F
200
0262
0562
0862
1162
3262
3562
3862
4162
680
J
200
0263
0563
0863
1163
3263
3563
3863
4163
680
K
200
0264
0564
0864
1164
3264
3564
3864
4164
820
F
200
0265
0565
0865
1165
3265
3565
3865
4165
820
J
200
0266
0566
0866
1166
3266
3566
3866
4166
820
K
200
0267
0567
0867
1167
3267
3567
3867
4167
1,000
F
200
0268
0568
0868
1168
3268
3568
3868
4168
1,000
J
200
0269
0569
0869
1169
3269
3569
3869
4169
1,000
K
200
0270
0570
0870
1170
3270
3570
3870
4170
1,200
F
200
0271
0571
0871
1171
3271
3571
3871
4171
1,200
J
200
0272
0572
0872
1172
3272
3572
3872
4172
1,200
K
200
0273
0573
0873
1173
3273
3573
3873
4173
2,700
F
100
0274
0574
0874
1174
3274
3574
3874
4174
2,700
J
100
0275
0575
0875
1175
3275
3575
3875
4175
2,700
K
100
0276
0576
0876
1176
3276
3576
3876
4176
3,300
F
100
0277
0577
0877
1177
3277
3577
3877
4177
3,300
J
100
0278
0578
0878
1178
3278
3578
3878
4178
3,300
K
100
0279
0579
0879
1179
3279
3579
3879
4179
4,700
F
50
0280
0580
0880
1180
3280
3580
3880
4180
4,700
J
50
0281
0581
0881
1181
3281
3581
3881
4181
4,700
K
50
0282
0582
0882
1182
3282
3582
3882
4182
5,600
F
50
0283
0583
0883
1183
3283
3583
3883
4183
5,600
J
50
0284
0584
0884
1184
3284
3584
3884
4184
5,600
K
50
0285
0585
0885
1185
3285
3585
3885
4185
6,800
F
50
0286
0586
0886
1186
3286
3586
3886
4186
6,800
J
50
0287
0587
0887
1187
3287
3587
3887
4187
6,800
K
50
See footnote at end of table.
