MIL-PRF-39014/22F
TABLE III. Dash numbers and electrical characteristics Continued.
Dash number
DC
Capaci-
Capaci-
Failure rate level (%/1,000 hours)
rated
tance
tance
voltage
Standard lead length 1/
Optional longer lead length 1/
tolerance
(pF)
(volts)
1.0(M)
0.1(P)
0.01(R)
0.001(S)
1.0(M)
0.1(P)
0.01(R)
0.001(S)
Style CKR24, Characteristic BX (voltage-temperature limits of +15% and +15, -25%).
0294
0594
0894
1194
3294
3594
3894
4194
270,000
K
50
0295
0595
0895
1195
3295
3595
3895
4195
270,000
M
50
0296
0596
0896
1196
3296
3596
3896
4196
330,000
K
50
0297
0597
0897
1197
3297
3597
3897
4197
330,000
M
50
0298
0598
0898
1198
3298
3598
3898
4198
390,000
K
50
0299
0599
0899
1199
3299
3599
3899
4199
390,000
M
50
0300
0600
0900
1200
3300
3600
3900
4200
470,000
K
50
0301
0601
0901
1201
3301
3601
3901
4201
470,000
M
50
0302
0602
0902
1202
3302
3602
3902
4202
560,000
K
50
0303
0603
0903
1203
3303
3603
3903
4203
560,000
M
50
0304
0604
0904
1204
3304
3604
3904
4204
680,000
K
50
0305
0605
0905
1205
3305
3605
3905
4205
680,000
M
50
0306
0606
0906
1206
3306
3606
3906
4206
820,000
K
50
0307
0607
0907
1207
3307
3607
3907
4207
820,000
M
50
0308
0608
0908
1208
3308
3608
3908
4208
1,000,000
K
50
0309
0609
0909
1209
3309
3609
3909
4209
1,000,000
M
50
Style CKR24, Characteristic BR (voltage-temperature limits of +15% and +15, -40%).
0240
0540
0840
1140
3240
3540
3840
4140
120,000
K
100
0310
0610
0910
1210
3310
3610
3910
4210
120,000
M
100
0241
0541
0841
1141
3241
3541
3841
4141
150,000
K
100
0242
0542
0842
1142
3242
3542
3842
4142
150,000
M
100
0243
0543
0843
1143
3243
3543
3843
4143
180,000
K
50
0311
0611
0911
1211
3311
3611
3911
4211
180,000
M
50
0244
0544
0844
1144
3244
3544
3844
4144
220,000
K
50
0245
0545
0845
1145
3245
3545
3845
4145
220,000
M
50
0246
0546
0846
1146
3246
3546
3846
4146
270,000
K
50
0312
0612
0912
1212
3312
3612
3912
4212
270,000
M
50
0247
0547
0847
1147
3247
3547
3847
4147
330,000
K
50
0248
0548
0848
1148
3248
3548
3848
4148
330,000
M
50
0249
0549
0849
1149
3249
3549
3849
4149
390,000
K
50
0313
0613
0913
1213
3313
3613
3913
4213
390,000
M
50
0250
0550
0850
1150
3250
3550
3850
4150
470,000
K
50
0251
0551
0851
1151
3251
3551
3851
4151
470,000
M
50
0252
0552
0852
1152
3252
3552
3852
4152
560,000
K
50
0253
0553
0853
1153
3253
3553
3853
4153
680,000
K
50
0254
0554
0854
1154
3254
3554
3854
4154
680,000
M
50
0255
0555
0855
1155
3255
3555
3855
4155
820,000
K
50
0256
0556
0856
1156
3256
3556
3856
4156
1,000,000
K
50
0257
0557
0857
1157
3257
3557
3857
4157
1,000,000
M
50
1/ See figure 1 for differences in lead length. The optional longer lead length is, with acquiring activity approval,
substitutable for the same part with standard lead length.
