INCH-POUND
MIL-PRF-39014/22F
28 October 2011
SUPERSEDING
MIL-PRF-39014/22E
7 December 2006
PERFORMANCE SPECIFICATION SHEET
CAPACITORS, FIXED, CERAMIC DIELECTRIC
(GENERAL PURPOSE),
ESTABLISHED RELIABILITY,
STYLES CKR22, CKR23, AND CKR24
This specification sheet is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist
of this specification sheet and MIL-PRF-39014.
Dimensions
Style
A ±.007
B
CKR22
.128
.175
CKR23
.155
.195
CKR24
.283
.320
FIGURE 1. Style CKR22, CKR23, and CKR24 capacitors.
AMSC N/A
FSC 5910
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
