MIL-PRF-19978/8A
TABLE II. STYLES CQR07 capacitors - Continued.
DC
Dimensions 2/
Part number 1/
voltage Capacitance Capacitance
Failure rate
Circuit 1
Circuit 2
rating
rating
tolerance
level
L .031  D +.015,  L .031  D +.015,
(Volts)
-.005
-.005
( F)
CQR07A-QB104-3-
100
.1
J, K
M, P, R, S
1.125
.400
1.062
.400
CQR07A-QB124-3-
100
.12
J, K
M, P, R, S
1.375
.562
1.312
.562
CQR07A-QB154-3-
100
.15
J, K
M, P, R, S
1.375
.562
1.312
.562
CQR07A-QB184-3-
100
.18
J, K
M, P, R, S
1.625
.562
1.562
.562
CQR07A-QB224-3-
100
.22
J, K
M, P, R, S
1.625
.562
1.562
.562
CQR07A-QB274-3-
100
.27
J, K
M, P, R, S
1.625
.670
1.562
.670
CQR07A-QB334-3-
100
.33
J, K
M, P, R, S
1.625
.670
1.562
.670
CQR07A-QB394-3-
100
.39
J, K
M, P, R, S
1.875
.750
1.812
.750
CQR07A-QB474-3-
100
.47
J, K
M, P, R, S
1.875
.750
1.812
.750
CQR07A-QB564-3-
100
.56
J, K
M, P, R, S
2.375
.750
2.312
.750
CQR07A-QB684-3-
100
.68
J, K
M, P, R, S
2.375
.750
2.312
.750
CQR07A-QB824-3-
100
.82
J, K
M, P, R, S
1.875
1.000
1.812
1.000
CQR07A-QB105-3-
100
1.0
J, K
M, P, R, S
1.875
1.000
1.812
1.000
CQR07A-QC102-3-
200
.001
J, K
M, P, R, S
.750
.175
.688
.175
CQR07A-QC122-3-
200
.0012
J, K
M, P, R, S
.750
.195
.688
.195
CQR07A-QC152-3-
200
.0015
J, K
M, P, R, S
.750
.195
.688
.195
CQR07A-QC182-3-
200
.0018
J, K
M, P, R, S
.750
.195
.688
.195
CQR07A-QC222-3-
200
.0022
J, K
M, P, R, S
.750
.195
.688
.195
CQR07A-QC272-3-
200
.0027
J, K
M, P, R, S
.750
.235
.688
.235
CQR07A-QC332-3-
200
.0033
J, K
M, P, R, S
.750
.235
.688
.235
CQR07A-QC822-3-
200
.082
J, K
M, P, R, S
.875
.312
.812
.312
CQR07A-QC103-3-
200
.01
J, K
M, P, R, S
.875
.312
.812
.312
CQR07A-QC123-3-
200
.012
J, K
M, P, R, S
.875
.312
.812
.312
CQR07A-QC153-3-
200
.015
J, K
M, P, R, S
.875
.312
.812
.312
CQR07A-QC183-3-
200
.018
J, K
M, P, R, S
.875
.400
.812
.400
CQR07A-QC223-3-
200
.022
J, K
M, P, R, S
.875
.400
.812
.400
CQR07A-QC273-3-
200
.027
J, K
M, P, R, S
1.125
.400
1.062
.400
CQR07A-QC333-3-
200
.033
J, K
M, P, R, S
1.125
.400
1.062
.400
CQR07A-QC393-3-
200
.039
J, K
M, P, R, S
1.125
.400
1.062
.400
CQR07A-QC473-3-
200
.047
J, K
M, P, R, S
1.125
.400
1.062
.400
CQR07A-QC563-3-
200
.056
J, K
M, P, R, S
1.125
.500
1.062
.500
CQR07A-QC683-3-
200
.068
J, K
M, P, R, S
1.125
.500
1.062
.500
CQR07A-QC823-3-
200
.082
J, K
M, P, R, S
1.125
.562
1.062
.562
CQR07A-QC104-3-
200
.1
J, K
M, P, R, S
1.125
.562
1.062
.562
CQR07A-QC124-3-
200
.12
J, K
M, P, R, S
1.875
.562
1.812
.562
CQR07A-QC154-3-
200
.15
J, K
M, P, R, S
1.875
.562
1.812
.562
CQR07A-QC184-3-
200
.18
J, K
M, P, R, S
1.875
.670
1.812
.670
CQR07A-QC224-3-
200
.22
J, K
M, P, R, S
1.875
.670
1.812
.670
CQR07A-QC274-3-
200
.27
J, K
M, P, R, S
2.125
.750
2.062
.750
CQR07A-QC334-3-
200
.33
J, K
M, P, R, S
2.125
.750
2.062
.750
CQR07A-QC394-3-
200
.39
J, K
M, P, R, S
1.875
1.000
1.812
1.000
CQR07A-QC474-3-
200
.47
J, K
M, P, R, S
1.875
1.000
1.812
1.000
CQR07A-QC564-3-
200
.56
J, K
M, P, R, S
2.125
1.000
2.062
1.000
CQR07A-QC684-3-
200
.68
J, K
M, P, R, S
2.125
1.000
2.062
1.000
CQR07A-QE122-3-
400
.0012
J, K
M, P, R, S
.750
.235
.688
.235
CQR07A-QE152-3-
400
.0015
J, K
M, P, R, S
.750
.235
.688
.235
CQR07A-QE392-3-
400
.0039
J, K
M, P, R, S
.875
.312
.812
.312
CQR07A-QE472-3-
400
.0047
J, K
M, P, R, S
.875
.312
.812
.312
CQR07A-QE562-3-
400
.0056
J, K
M, P, R, S
.875
.312
.812
.312
CQR07A-QE682-3-
400
.0068
J, K
M, P, R, S
.875
.312
.812
.312
See footnotes at end of table
