MIL-PRF-19978/8A
Test temperature - +125 C +0 C, -5 C.
Capacitance change (max) - +1 percent, -4 percent.
Life:
Capacitance change (max) - +2 percent, -1 percent.
Resistance to soldering heat: In accordance with MIL-PRF-19978.
TABLE II. STYLES CQR07 capacitors.
DC
Dimensions 2/
Part number 1/
voltage Capacitance Capacitance
Failure rate
Circuit 1
Circuit 2
rating
rating
tolerance
level
L .031 D +.015, L .031 D +.015,
(Volts)
-.005
-.005
( F)
CQR07A-QA392-3-
50
.0039
J, K
M, P, R, S
.750
.175
.688
.175
CQR07A-QA472-3-
50
.0047
J, K
M, P, R, S
.750
.175
.688
.175
CQR07A-QA562-3-
50
.0056
J, K
M, P, R, S
.750
.195
.688
.195
CQR07A-QA682-3-
50
.0068
J, K
M, P, R, S
.750
.195
.688
.195
CQR07A-QA393-3-
50
.039
J, K
M, P, R, S
.875
.312
.812
.312
CQR07A-QA473-3-
50
.047
J, K
M, P, R, S
.875
.312
.812
.312
CQR07A-QA563-3-
50
.056
J, K
M, P, R, S
.875
.400
.812
.400
CQR07A-QA683-3-
50
.068
J, K
M, P, R, S
.875
.400
.812
.400
CQR07A-QA823-3-
50
.082
J, K
M, P, R, S
.875
.400
.812
.400
CQR07A-QA104-3-
50
.1
J, K
M, P, R, S
.875
.400
.812
.400
CQR07A-QA124-3-
50
.12
J, K
M, P, R, S
1.375
.400
1.312
.400
CQR07A-QA154-3-
50
.15
J, K
M, P, R, S
1.375
.400
1.312
.400
CQR07A-QA184-3-
50
.18
J, K
M, P, R, S
1.125
.562
1.062
.562
CQR07A-QA224-3-
50
.22
J, K
M, P, R, S
1.125
.562
1.062
.562
CQR07A-QA274-3-
50
.27
J, K
M, P, R, S
1.375
.562
1.312
.562
CQR07A-QA334-3-
50
.33
J, K
M, P, R, S
1.375
.562
1.312
.562
CQR07A-QA394-3-
50
.39
J, K
M, P, R, S
1.875
.562
1.812
.562
CQR07A-QA474-3-
50
.47
J, K
M, P, R, S
1.875
.562
1.812
.562
CQR07A-QA564-3-
50
.56
J, K
M, P, R, S
1.875
.670
1.812
.670
CQR07A-QA684-3-
50
.68
J, K
M, P, R, S
1.875
.670
1.812
.670
CQR07A-QA824-3-
50
.82
J, K
M, P, R, S
1.875
.750
1.812
.750
CQR07A-QA105-3-
50
1.0
J, K
M, P, R, S
1.875
.750
1.812
.750
CQR07A-QB222-3-
100
.0022
J, K
M, P, R, S
.750
.175
.688
.175
CQR07A-QB272-3-
100
.0027
J, K
M, P, R, S
.750
.175
.688
.175
CQR07A-QB332-3-
100
.0033
J, K
M, P, R, S
.750
.175
.688
.175
CQR07A-QB392-3-
100
.0039
J, K
M, P, R, S
.750
.195
.688
.195
CQR07A-QB472-3-
100
.0047
J, K
M, P, R, S
.750
.195
.688
.195
CQR07A-QB562-3-
100
.0056
J, K
M, P, R, S
.750
.235
.688
.235
CQR07A-QB682-3-
100
.0068
J, K
M, P, R, S
.750
.235
.688
.235
CQR07A-QB822-3-
100
.0082
J, K
M, P, R, S
.750
.235
.688
.235
CQR07A-QB103-3-
100
.01
J, K
M, P, R, S
.750
.235
.688
.235
CQR07A-QB183-3-
100
.018
J, K
M, P, R, S
.875
.312
.812
.312
CQR07A-QB223-3-
100
.022
J, K
M, P, R, S
.875
.312
.812
.312
CQR07A-QB273-3-
100
.027
J, K
M, P, R, S
.875
.312
.812
.312
CQR07A-QB333-3-
100
.033
J, K
M, P, R, S
.875
.312
.812
.312
CQR07A-QB393-3-
100
.039
J, K
M, P, R, S
.875
.400
.812
.400
CQR07A-QB473-3-
100
.047
J, K
M, P, R, S
.875
.400
.812
.400
CQR07A-QB563-3-
100
.056
J, K
M, P, R, S
1.125
.400
1.062
.400
CQR07A-QB683-3-
100
.068
J, K
M, P, R, S
1.125
.400
1.062
.400
CQR07A-QB823-3-
100
.082
J, K
M, P, R, S
1.125
.400
1.062
.400
