MIL-PRF-19978/8A
TABLE I. Terminal-to-terminal insulation resistance.
Capacitance rating
Minimum insulation resistance
Characteristic Q
At 25 C
0 to 0.5 microfarad
150,000 megohms
Greater than 0.5 microfarad
75,000 megohm-microfarads 1/
At 125 C
0 to 0.1 microfarad
5,000 megohms
Greater than 0.1 microfarad
500 megohm-microfarads 1/
1/ Product obtained by multiplying the capacitance in microfarads by the insulation
resistance in megohms.
Vibration, high frequency: Method 204 of MIL-STD-202, test condition B, with the following exception:
Direction and duration of motion - 4 hours in each of two mutually perpendicular direction (total of 8 hours), one
parallel and the other perpendicular to the cylindrical axis.
Salt spray: In accordance with MIL-PRF-19978.
Immersion:
DWV:
Sleeving - In accordance with MIL-PRF-19978.
IR:
Sleeving - In accordance with MIL-PRF-19978.
Solderability: In accordance with MIL-PRF-19978.
Terminal strength: Method 211 of MIL-STD-202, test condition letter D.
Moisture resistance:
DWV:
Sleeving - In accordance with MIL-PRF-19978.
IR:
Sleeving - In accordance with MIL-PRF-19978.
Dielectric absorption (not applicable to values of 0.01 F or less) (max): 0.04 percent.
Stability at low and high temperatures:
Low temperature:
Test temperature - -55 C +0 C, -5 C.
Capacitance change (max) -
2.5 percent.
High temperature:
