MIL-PRF-19978/13C
TABLE II. STYLES CQR29 capacitors - Continued.
Case dimensions 2/
DC
Circuit 1
Circuit 3
Capacitance Capacitance
Failure
Part number 1/
voltage
L ±.031 D +.015, L ±.031 D +.015,
rating
tolerance
rate level
rating
-.005
-.005
µF
Volts
Inches
Inches
Inches
Inches
CQR29A-MF333-3-
600
.033
G, J, K
M, P, R, S
1.312
.400
1.219
.400
CQR29A-MF393-3-
600
.039
G, J, K
M, P, R, S
1.562
.400
1.469
.400
CQR29A-MF473-3-
600
.047
G, J, K
M, P, R, S
1.562
.400
1.469
.400
CQR29A-MF563-3-
600
.056
G, J, K
M, P, R, S
1.250
.562
1.156
.562
CQR29A-MF683-3-
600
.068
G, J, K
M, P, R, S
1.250
.562
1.156
.562
CQR29A-MF823-3-
600
.082
G, J, K
M, P, R, S
1.500
.562
1.406
.562
CQR29A-MF104-3-
600
.10
G, J, K
M, P, R, S
1.500
.562
1.406
.562
CQR29A-MF124-3-
600
.12
G, J, K
M, P, R, S
1.875
.562
1.781
.562
CQR29A-MF154-3-
600
.15
G, J, K
M, P, R, S
1.875
.562
1.781
.562
CQR29A-MF184-3-
600
.18
G, J, K
M, P, R, S
1.875
.670
1.781
.670
CQR29A-MF224-3-
600
.22
G, J, K
M, P, R, S
1.875
.670
1.781
.670
CQR29A-MF274-3-
600
.27
G, J, K
M, P, R, S
2.125
.750
2.031
.750
CQR29A-MF334-3-
600
.33
G, J, K
M, P, R, S
2.125
.750
2.031
.750
CQR29A-MF394-3-
600
.39
G, J, K
M, P, R, S
2.625
.750
2.531
.750
CQR29A-MF474-3-
600
.47
G, J, K
M, P, R, S
2.625
.750
2.531
.750
CQR29A-MF564-3-
600
.56
G, J, K
M, P, R, S
2.125
1.000
2.031
1.000
CQR29A-MF684-3-
600
.68
G, J, K
M, P, R, S
2.125
1.000
2.031
1.000
CQR29A-MG102-3-
1000
.0010
G, J, K
M, P, R, S
.938
.312
.844
.312
CQR29A-MG122-3-
1000
.0012
G, J, K
M, P, R, S
.938
.312
.844
.312
CQR29A-MG152-3-
1000
.0015
G, J, K
M, P, R, S
.938
.312
.844
.312
CQR29A-MG182-3-
1000
.0018
G, J, K
M, P, R, S
.938
.312
.844
.312
CQR29A-MG222-3-
1000
.0022
G, J, K
M, P, R, S
.938
.312
.844
.312
CQR29A-MG272-3-
1000
.0027
G, J, K
M, P, R, S
.938
.312
.844
.312
CQR29A-MG332-3-
1000
.0033
G, J, K
M, P, R, S
.938
.312
.844
.312
CQR29A-MG392-3-
1000
.0039
G, J, K
M, P, R, S
.938
.400
.844
.400
CQR29A-MG472-3-
1000
.0047
G, J, K
M, P, R, S
.938
.400
.844
.400
CQR29A-MG562-3-
1000
.0056
G, J, K
M, P, R, S
1.062
.400
.969
.400
CQR29A-MG682-3-
1000
.0068
G, J, K
M, P, R, S
1.062
.400
.969
.400
CQR29A-MG822-3-
1000
.0082
G, J, K
M, P, R, S
1.312
.400
1.219
.400
CQR29A-MG103-3-
1000
.010
G, J, K
M, P, R, S
1.312
.400
1.219
.400
CQR29A-MG123-3-
1000
.012
G, J, K
M, P, R, S
1.562
.400
1.469
.400
CQR29A-MG183-3-
1000
.018
G, J, K
M, P, R, S
1.250
.562
1.156
.562
CQR29A-MG223-3-
1000
.022
G, J, K
M, P, R, S
1.250
.562
1.156
.562
CQR29A-MG273-3-
1000
.027
G, J, K
M, P, R, S
1.250
.562
1.156
.562
CQR29A-MG333-3-
1000
.033
G, J, K
M, P, R, S
1.500
.562
1.406
.562
CQR29A-MG393-3-
1000
.039
G, J, K
M, P, R, S
1.875
.562
1.781
.562
CQR29A-MG473-3-
1000
.047
G, J, K
M, P, R, S
1.875
.562
1.781
.562
CQR29A-MG563-3-
1000
.056
G, J, K
M, P, R, S
1.875
.670
1.781
.670
CQR29A-MG683-3-
1000
.068
G, J, K
M, P, R, S
1.875
.670
1.781
.670
CQR29A-MG823-3-
1000
.082
G, J, K
M, P, R, S
2.125
.750
2.031
.750
CQR29A-MG104-3-
1000
.10
G, J, K
M, P, R, S
2.125
.750
2.031
.750
CQR29A-MG124-3-
1000
.12
G, J, K
M, P, R, S
1.875
1.000
1.781
1.000
CQR29A-MG154-3-
1000
.15
G, J, K
M, P, R, S
1.875
1.000
1.781
1.000
CQR29A-MG184-3-
1000
.18
G, J, K
M, P, R, S
2.375
1.000
2.281
1.000
CQR29A-MG224-3-
1000
.22
G, J, K
M, P, R, S
2.375
1.000
2.281
1.000
1/ Complete part number shall include additional symbols to indicate circuit symbol, capacitance tolerance, and
failure rate level, as applicable.
2/ Dimensions are for basic case; sleeving shall extend .016 inch minimum and .062 inch maximum, beyond each
end of the capacitor body; however, if a shrink-fitted insulation is used for the sleeving, it shall lap over the ends
of the capacitor body. Add .047 inch maximum to the nominal for capacitance diameter.
7
