MIL-PRF-19978/13C
TABLE II. STYLES CQR29 capacitors - Continued.
Case dimensions 2/
DC
Circuit 1
Circuit 3
Capacitance Capacitance
Failure
Part number 1/
voltage
L ±.031 D +.015, L ±.031 D +.015,
rating
tolerance
rate level
rating
-.005
-.005
µF
Volts
Inches
Inches
Inches
Inches
CQR29A-MB185-3-
100
1.8
G, J, K
M, P, R, S
1.625
.670
1.531
.670
CQR29A-MB225-3-
100
2.2
G, J, K
M, P, R, S
1.875
.750
1.781
.750
CQR29A-MB275-3-
100
2.7
G, J, K
M, P, R, S
2.125
.750
2.031
.750
CQR29A-MB335-3-
100
3.3
G, J, K
M, P, R, S
2.375
.750
2.281
.750
CQR29A-MB395-3-
100
3.9
G, J, K
M, P, R, S
1.875
1.000
1.781
1.000
CQR29A-MB475-3-
100
4.7
G, J, K
M, P, R, S
2.125
1.000
2.031
1.000
CQR29A-MB565-3-
100
5.6
G, J, K
M, P, R, S
2.375
1.000
2.281
1.000
CQR29A-MB685-3-
100
6.8
G, J, K
M, P, R, S
2.625
1.000
2.531
1.000
CQR29A-MC102-3-
200
.0010
G, J, K
M, P, R, S
.750
.175
.656
.175
CQR29A-MC122-3-
200
.0012
G, J, K
M, P, R, S
.750
.175
.656
.175
CQR29A-MC152-3-
200
.0015
G, J, K
M, P, R, S
.750
.175
.656
.175
CQR29A-MC182-3-
200
.0018
G, J, K
M, P, R, S
.750
.175
.656
.175
CQR29A-MC222-3-
200
.0022
G, J, K
M, P, R, S
.750
.175
.656
.175
CQR29A-MC272-3-
200
.0027
G, J, K
M, P, R, S
.750
.175
.656
.175
CQR29A-MC332-3-
200
.0033
G, J, K
M, P, R, S
.750
.175
.656
.175
CQR29A-MC392-3-
200
.0039
G, J, K
M, P, R, S
.750
.175
.656
.175
CQR29A-MC472-3-
200
.0047
G, J, K
M, P, R, S
.750
.175
.656
.175
CQR29A-MC562-3-
200
.0056
G, J, K
M, P, R, S
.750
.175
.656
.175
CQR29A-MC682-3-
200
.0068
G, J, K
M, P, R, S
.750
.175
.656
.175
CQR29A-MC822-3-
200
.0082
G, J, K
M, P, R, S
.750
.175
.656
.175
CQR29A-MC103-3-
200
.010
G, J, K
M, P, R, S
.750
.175
.656
.175
CQR29A-MC123-3-
200
.012
G, J, K
M, P, R, S
.719
.195
.625
.195
CQR29A-MC153-3-
200
.015
G, J, K
M, P, R, S
.719
.195
.625
.195
CQR29A-MC183-3-
200
.018
G, J, K
M, P, R, S
.719
.235
.625
.235
CQR29A-MC223-3-
200
.022
G, J, K
M, P, R, S
.719
.235
.625
.235
CQR29A-MC273-3-
200
.027
G, J, K
M, P, R, S
.719
.235
.625
.235
CQR29A-MC333-3-
200
.033
G, J, K
M, P, R, S
.719
.235
.625
.235
CQR29A-MC393-3-
200
.039
G, J, K
M, P, R, S
.719
.312
.625
.312
CQR29A-MC473-3-
200
.047
G, J, K
M, P, R, S
.719
.312
.625
.312
CQR29A-MC563-3-
200
.056
G, J, K
M, P, R, S
.844
.312
.750
.312
CQR29A-MC683-3-
200
.068
G, J, K
M, P, R, S
.844
.312
.750
.312
CQR29A-MC823-3-
200
.082
G, J, K
M, P, R, S
.844
.312
.750
.312
CQR29A-MC104-3-
200
.10
G, J, K
M, P, R, S
.844
.312
.750
.312
CQR29A-MC124-3-
200
.12
G, J, K
M, P, R, S
.812
.400
.718
.400
CQR29A-MC154-3-
200
.15
G, J, K
M, P, R, S
.812
.400
.718
.400
CQR29A-MC184-3-
200
.18
G, J, K
M, P, R, S
1.062
.400
.969
.400
CQR29A-MC224-3-
200
.22
G, J, K
M, P, R, S
1.062
.400
.969
.400
CQR29A-MC274-3-
200
.27
G, J, K
M, P, R, S
1.250
.400
1.156
.400
CQR29A-MC334-3-
200
.33
G, J, K
M, P, R, S
1.250
.400
1.156
.400
CQR29A-MC394-3-
200
.39
G, J, K
M, P, R, S
1.188
.500
1.094
.500
CQR29A-MC474-3-
200
.47
G, J, K
M, P, R, S
1.188
.500
1.094
.500
CQR29A-MC564-3-
200
.56
G, J, K
M, P, R, S
1.375
.562
1.281
.562
CQR29A-MC684-3-
200
.68
G, J, K
M, P, R, S
1.375
.562
1.281
.562
CQR29A-MC824-3-
200
.82
G, J, K
M, P, R, S
1.875
.562
1.781
.562
CQR29A-MC105-3-
200
1.0
G, J, K
M, P, R, S
1.875
.562
1.781
.562
CQR29A-ME102-3-
400
.0010
G, J, K
M, P, R, S
.812
.235
.718
.235
CQR29A-ME122-3-
400
.0012
G, J, K
M, P, R, S
.812
.235
.718
.235
CQR29A-ME152-3-
400
.0015
G, J, K
M, P, R, S
.812
.235
.718
.235
CQR29A-ME182-3-
400
.0018
G, J, K
M, P, R, S
.812
.235
.718
.235
CQR29A-ME222-3-
400
.0022
G, J, K
M, P, R, S
.812
.235
.718
.235
