MIL-PRF-19978/13C
TABLE I. Terminal-to-terminal insulation resistance.
Capacitance rating
Minimum insulation resistance
Characteristic M
At +25°C
0 to 0.68 microfarad
100,000 megohms
Greater than 0.68 microfarad
68,000 megohm-microfarads 1/
At +85°C
0 to 0.2 microfarad
25,000 megohms
Greater than 0.2 microfarad
5,000 megohm-microfarads 1/
1/ Product obtained by multiplying the capacitance in microfarads by the insulation
resistance in megohms.
Salt atmosphere (corrosion): In accordance with MIL-PRF-19978.
Immersion:
DWV:
Sleeving - In accordance with MIL-PRF-19978.
IR:
Sleeving - In accordance with MIL-PRF-19978.
Solderability: In accordance with MIL-PRF-19978.
Terminal strength: Method 211 of MIL-STD-202, test condition letter D.
Moisture resistance:
DWV:
Sleeving - In accordance with MIL-PRF-19978.
IR:
Sleeving - In accordance with MIL-PRF-19978.
Dielectric absorption (not applicable to values of 0.01 µF or less): 0.60 percent, maximum.
Stability at low and high temperature:
Low temperature:
Test temperature -65°C +0°C, -5°C.
Capacitance change (max) - -7 percent.
High temperature:
Test temperature - +85°C +5°C, -0°C.
Capacitance change (max) - +5 percent.
