MIL-PRF-19978/13C
TABLE II. STYLES CQR29 capacitors - Continued.
Case dimensions 2/
DC
Circuit 1
Circuit 3
Capacitance Capacitance
Failure
Part number 1/
voltage
L ±.031 D +.015, L ±.031 D +.015,
rating
tolerance
rate level
rating
-.005
-.005
µF
Volts
Inches
Inches
Inches
Inches
CQR29A-ME272-3-
400
.0027
G, J, K
M, P, R, S
.812
.235
.718
.235
CQR29A-ME332-3-
400
.0033
G, J, K
M, P, R, S
.812
.235
.718
.235
CQR29A-ME392-3-
400
.0039
G, J, K
M, P, R, S
.812
.235
.718
.235
CQR29A-ME472-3-
400
.0047
G, J, K
M, P, R, S
.812
.235
.718
.235
CQR29A-ME562-3-
400
.0056
G, J, K
M, P, R, S
.938
.312
.844
.312
CQR29A-ME682-3-
400
.0068
G, J, K
M, P, R, S
.938
.312
.844
.312
CQR29A-ME822-3-
400
.0082
G, J, K
M, P, R, S
.938
.312
.844
.312
CQR29A-ME103-3-
400
.010
G, J, K
M, P, R, S
.938
.312
.844
.312
CQR29A-ME123-3-
400
.012
G, J, K
M, P, R, S
.938
.312
.844
.312
CQR29A-ME153-3-
400
.015
G, J, K
M, P, R, S
.938
.312
.844
.312
CQR29A-ME183-3-
400
.018
G, J, K
M, P, R, S
1.062
.312
.969
.312
CQR29A-ME223-3-
400
.022
G, J, K
M, P, R, S
1.062
.312
.969
.312
CQR29A-ME273-3-
400
.027
G, J, K
M, P, R, S
.938
.400
.844
.400
CQR29A-ME333-3-
400
.033
G, J, K
M, P, R, S
.938
.400
.844
.400
CQR29A-ME393-3-
400
.039
G, J, K
M, P, R, S
1.062
.400
.969
.400
CQR29A-ME473-3-
400
.047
G, J, K
M, P, R, S
1.062
.400
.969
.400
CQR29A-ME563-3-
400
.056
G, J, K
M, P, R, S
1.250
.400
1.156
.400
CQR29A-ME683-3-
400
.068
G, J, K
M, P, R, S
1.250
.400
1.156
.400
CQR29A-ME823-3-
400
.082
G, J, K
M, P, R, S
1.562
.400
1.469
.400
CQR29A-ME104-3-
400
.10
G, J, K
M, P, R, S
1.562
.400
1.469
.400
CQR29A-ME124-3-
400
.12
G, J, K
M, P, R, S
1.281
.562
1.188
.562
CQR29A-ME154-3-
400
.15
G, J, K
M, P, R, S
1.281
.562
1.188
.562
CQR29A-ME184-3-
400
.18
G, J, K
M, P, R, S
1.531
.562
1.438
.562
CQR29A-ME224-3-
400
.22
G, J, K
M, P, R, S
1.531
.562
1.438
.562
CQR29A-ME274-3-
400
.27
G, J, K
M, P, R, S
1.906
.562
1.812
.562
CQR29A-ME334-3-
400
.33
G, J, K
M, P, R, S
1.906
.562
1.812
.562
CQR29A-ME394-3-
400
.39
G, J, K
M, P, R, S
1.906
.670
1.812
.670
CQR29A-ME474-3-
400
.47
G, J, K
M, P, R, S
1.906
.670
1.812
.670
CQR29A-ME564-3-
400
.56
G, J, K
M, P, R, S
2.156
.750
2.062
.750
CQR29A-ME684-3-
400
.68
G, J, K
M, P, R, S
2.156
.750
2.062
.750
CQR29A-ME824-3-
400
.82
G, J, K
M, P, R, S
2.656
.750
2.562
.750
CQR29A-ME105-3-
400
1.0
G, J, K
M, P, R, S
2.656
.750
2.562
.750
CQR29A-MF102-3-
600
.0010
G, J, K
M, P, R, S
.812
.235
.718
.235
CQR29A-MF122-3-
600
.0012
G, J, K
M, P, R, S
.812
.235
.718
.235
CQR29A-MF152-3-
600
.0015
G, J, K
M, P, R, S
.812
.235
.718
.235
CQR29A-MF182-3-
600
.0018
G, J, K
M, P, R, S
.812
.235
.718
.235
CQR29A-MF222-3-
600
.0022
G, J, K
M, P, R, S
.812
.235
.718
.235
CQR29A-MF272-3-
600
.0027
G, J, K
M, P, R, S
.812
.235
.718
.235
CQR29A-MF332-3-
600
.0033
G, J, K
M, P, R, S
.938
.312
.844
.312
CQR29A-MF392-3-
600
.0039
G, J, K
M, P, R, S
.938
.312
.844
.312
CQR29A-MF472-3-
600
.0047
G, J, K
M, P, R, S
.938
.312
.844
.312
CQR29A-MF562-3-
600
.0056
G, J, K
M, P, R, S
.938
.312
.844
.312
CQR29A-MF682-3-
600
.0068
G, J, K
M, P, R, S
.938
.312
.844
.312
CQR29A-MF822-3-
600
.0082
G, J, K
M, P, R, S
1.062
.312
.969
.312
CQR29A-MF103-3-
600
.010
G, J, K
M, P, R, S
1.062
.312
.969
.312
CQR29A-MF123-3-
600
.012
G, J, K
M, P, R, S
.938
.400
.844
.400
CQR29A-MF153-3-
600
.015
G, J, K
M, P, R, S
.938
.400
.844
.400
CQR29A-MF183-3-
600
.018
G, J, K
M, P, R, S
1.062
.400
.969
.400
CQR29A-MF223-3-
600
.022
G, J, K
M, P, R, S
1.062
.400
.969
.400
CQR29A-MF273-3-
600
.027
G, J, K
M, P, R, S
1.312
.400
1.219
.400
