MIL-C-62F
b.
Test condition: B, applicable to solder lugs.
Number of bending operations: Three.
c.
Test condition: D, applicable to axial-wire leads.
d.
Test condition: E, applicable to solder-lug and screw-insert terminals.
Applied force: As specified in table VII.
e.
Examination after test: Terminals shall be examined for loosening or permanent damage, and the terminal
weld or solder joint shall be examined for perceptible movement relative to the case (see 3.9).
TABLE VII. Terminal strength.
Type of terminal
Pull
Torque
Pounds
Pound-inches
---
5
Axial-wire lead
1
5
Solder lug
10
10
Screw-insert
4.5.7 Shock, (specified pulse) (see 3.10). Capacitors shall be tested in accordance with
method 213 of MIL-STD-202. The following details and exceptions shall apply:
a.
Special mounting means: Rigidly mounted by the body; axial-wire-lead capacitors shall be fastened to
rigidly supported terminals.
b.
Test condition: I, except for styles CE70 and CE71, test condition H shall apply.
c.
Measurements during and after shock: During the test, an electrical measurement shall be made to
determine intermittent contacts or arcing or open-or short-circuiting. Detecting equipment shall be
sufficiently sensitive to detect an interruption with a duration of 0.5 ms or greater.
d.
Examination after test: Capacitors shall be visually examined for mechanical damage.
4.5.8 Vibration (see 3.11).
4.5.8.1 Low frequency (applicable only to styles CE63, CE64, CE70, and CE71). Capacitors shall be tested in
accordance with method 201 of MIL-STD-202. The following details and exceptions shall apply:
a.
Tests and measurements prior to vibration: Not applicable.
Method of mounting: Securely fastened by normal mounting means (see table III and 3.1).
b.
c.
Duration of vibration: 1.5 hours.
d.
Direction of motion: 45 minutes in each of two mutually perpendicular directions, an electrical
measurement shall be made to determine intermittent contacts or open- or short-circuiting. Detecting
equipment shall be sufficiently sensitive to detect any interruption with a duration of 0.5 ms or greater.
e.
Examinations after test: Capacitors shall be visually examined for mechanical damage and leakage of the
electrolyte.
13
