MIL-C-11015/19E
Life (at elevated ambient temperature): In accordance with MIL-C-11015.
Test potential - 200 percent of rated voltage.
IR - 1,000 megohms, min or 10 megohm-microfarads, min, whichever is less (at 125 C), and not less than
10 percent of initial requirement (at 25 C).
C - Shall not exceed 20 percent from initial measured value.
DF - 2.5 percent, max (at 25 C).
Marking: In accordance with MIL-C-11015, and as shown in figure 1.
Changes from previous issue: Marginal notations are not used in this revision to identify changes with respect to
the previous issue due to the extent of the changes.
Supersession data: Items having a "CW" voltage-temperature limit formerly covered by Rev. A, and earlier issues,
of this specification sheet are superseded as indicated in table II.
TABLE II. Cross-reference of substitute items.
Superseded
Recommended
Superseded
Recommended
item 1/
substitute
item 1/
Substitute
item 1/
Item 1/
CK06CW122K
CK06BX122K
CK06CW392K
CK06BX392K
CK06CW152-
CK06BX152-
CK06CW472-
CK06BX472-
CK06CW182K
CK06BX182K
CK06CW562K
CK06BX562K
CK06CW222-
CK06BX222-
CK06CW682-
CK06BX682-
CK06CW272K
CK06BX272K
CK06CW822K
CK06BX822K
CK06CW332-
CK06BX332-
CK06CW103-
CK06BX103-
1/ Where required, the PIN will include comparable capacitance tolerance symbol.
Inactivated styles: For new design units of MIL-PRF-39014/2 should be used as listed in table III. Although table
III lists only the highest failure rate level, lower failure rate levels may be considered. For substitutability of the
inactivated styles, established reliability capacitors in MIL-PRF-39014/2 of the same capacitance value, tolerance,
rated voltage and temperature coefficient can be used regardless of the failure rate designation.
5
