MIL-C-11015/19E
TABLE I. Style CK06 characteristics.
Rated temperature
and voltage-
Capacitance
Capacitance
PIN 1/
Rated
temperature limits
tolerance
Voltage
Volts, dc
pF
CK06BX122K
200
BX
1,200
K
CK06BX152-
200
BX
1,500
K, M
CK06BX182K
200
BX
1,800
K
CK06BX222-
200
BX
2,200
K, M
CK06BX272K
200
BX
2,700
K
CK06BX332-
200
BX
3,300
K, M
CK06BX392K
200
BX
3,900
K
CK06BX472-
200
BX
4,700
K, M
CK06BX562K
200
BX
5,600
K
CK06BX682-
200
BX
6,800
K, M
CK06BX822K
200
BX
8,200
K
CK06BX103-
200
BX
10,000
K, M
CK06BX123K
100
BX
12,000
K
CK06BX153-
100
BX
15,000
K, M
CK06BX183K
100
BX
18,000
K
CK06BX223-
100
BX
22,000
K, M
CK06BX273K
100
BX
27,000
K
CK06BX333-
100
BX
33,000
K, M
CK06BX393K
100
BX
39,000
K
CK06BX473-
100
BX
47,000
K, M
CK06BX563K
100
BX
56,000
K
CK06BX683-
100
BX
68,000
K, M
CK06BX823K
100
BX
82,000
K
CK06BX104-
100
BX
100,000
K, M
CK06BX124K
50
BX
120,000
K
CK06BX154-
50
BX
150,000
K, M
CK06BX184K
50
BX
180,000
K
CK06BX224-
50
BX
220,000
K, M
CK06BX274K
50
BX
270,000
K
CK06BX334-
50
BX
330,000
K, M
CK06BX394K
50
BX
390,000
K
CK06BX474-
50
BX
470,000
K, M
CK06BX564K
50
BX
560,000
K
CK06BX684-
50
BX
680,000
K, M
CK06BX824K
50
BX
820,000
K
CK06BX105-
50
BX
1,000,000
K, M
1/ Where applicable, the complete PIN will include an additional symbol to indicate capacitance tolerance.
