MIL-PRF-39014/5G
TABLE I. Dash number and electrical characteristics - Continued.
Dash number
Capacitance
Capacitance
DC
Failure rate level (%/1,000 hours)
tolerance
rated
1.0 (M)
0.1(P)
0.01(R)
0.001(S)
voltage
Style CKR11, voltage-temperature limits of ±15 percent and +15 percent, -25 percent
pF
± percent
volts
2648
2848
2048
2248
3,900
10
100
2649
2849
2049
2249
4,700
10
100
2650
2850
2050
2250
4,700
20
100
2651
2851
2051
2251
5,600
10
50
2652
2852
2052
2252
6,800
10
50
2653
2853
2053
2253
6,800
20
50
2654
2854
2054
2254
8,200
10
50
2655
2855
2055
2255
10,000
10
50
2656
2856
2056
2256
10,000
20
50
Style CKR12, voltage-temperature limits of ±15 percent and +15 percent, -25 percent
pF
± percent
volts
2657
2857
2057
2257
5,600
10
100
2658
2858
2058
2258
6,800
10
100
2659
2859
2059
2259
6,800
20
100
2660
2860
2060
2260
8,200
10
100
2661
2861
2061
2261
10,000
10
100
2662
2862
2062
2262
10,000
20
100
2663
2863
2063
2263
12,000
10
50
2664
2864
2064
2264
15,000
10
50
2665
2865
2065
2265
15,000
20
50
2666
2866
2066
2266
18,000
10
50
2667
2867
2067
2267
22,000
10
50
2668
2868
2068
2268
22,000
20
50
2669
2869
2069
2269
27,000
10
50
2670
2870
2070
2270
33,000
10
50
2671
2871
2071
2271
33,000
20
50
2672
2872
2072
2272
39,000
10
50
2673
2873
2073
2273
47,000
10
50
2674
2874
2074
2274
47,000
20
50
6
