MIL-PRF-39014/5G
NOTE: As indicated in table II, CKR12 items previously covered by MIL-C-39014/5A and MIL-C-39014/5 are now
replaced by smaller CKR11 items. It is also to be noted that units of 6,800- pF and 10,000-pF capacitance values
rated at 100 volts dc at 85°C (50 percent derating for 125°C) are replaced with units rated at 50 volts at both 85°C
and 125°C.
EXAMPLE:
MIL-C-39014/5
MIL-C-39014/5A
MIL-C-39014/5B
MIL-C-39014/5C, /5D, /5E
and MIL-PRF-39014, /5F
and /5G
M39014/05-0177
M39014/05-0247
M39014/05-0656
M39014/05-2656
100 V
100 V
50 V
50 V
(Derated 50%
(Derated 50%
(Not derated
(Not derated
at 125°C)
at 125°C)
at 125°C)
at 125°C)
Since all previous failure rate level testing was accomplished at 125°C, no failure rate level was ever established for
the 85°C rating. The newer items in regard to FR level testing more closely resemble the items they supersede.
Packaging: Capacitors will be furnished in tape and reel packaging when so specified in the ordering data.
Glass cases shall no longer be supplied to this specification sheet
Substitutability for failure rate levels shall be as follows:
Will replace failure rate level
Failure rate level
S
R, P, M, L
R
P, M, L
P
M, L
M
L
Equivalent NATO styles. The equivalent NATO styles per NATO-NEPR No. 14 shall be as follows:
Military style
NATO
style
CKR11
NCC75
CKR12
NCC70
CKR14
NCC72
CKR15
NCC73
*
NOTES:
Reference document. MIL-PRF-39014.
*
Changes from previous issue. The margins of this specification are marked with asterisks to indicate where changes
from the previous issue were made. This was done as a convenience only and the Government assumes no liability
whatsoever for any inaccuracies in these notations. Bidders and contractors are cautioned to evaluate the
requirements of this document based on the entire content irrespective of the marginal notations and relationship to
the last previous issue.
12
