MIL-PRF-39014/5G
REQUIREMENTS:
Dimensions and configuration - See figure 1.
Case type - Tubular, molded or performed plastic encapsulated.
Capacitance value - See table I.
Capacitance tolerance - See table I.
Operating temperature range - -55°C to +125°C.
Voltage rating - See table I.
Radiographic inspection (failure rate level S only - In accordance with MIL-PRF-39014.
Dissipation factor (DF) - Not more than 2.5 percent for BX; not more than 3.0 percent for BR.
Dielectric withstanding voltage - Body insulation shall be able to withstand 500 Vdc between leads and case.
Insulation resistance (IR):
At 25°C
-
Not less than 100,000 megohms or 1,000 megohm-microfarads whichever is less.
At 125°C -
Not less than 10,000 megohms or 100 megohm-microfarads whichever is less.
Seal - Not applicable.
Voltage-temperature limits - In accordance with MIL-PRF-39014.
Capacitance change with reference to 25°C
Symbol
Step E through step G of table VI of
Step A through step D of table VI of
Bias = rated voltage
Bias = 0 volts
BX
±15 percent
+15 percent, -25 percent
as applicable (see table I)
BR
±15 percent
+15 percent, -40 percent
as applicable (see table I)
Immersion (IR) - IR not less than 50 percent of initial 25°C requirement.
Salt spray (corrosion) - Not applicable.
Resistance to soldering heat - ĆC +15, -5 percent of the initial 25°C measurement.
