MIL-PRF-39014/1H
TABLE I. Dash number and electrical characteristics - Continued.
DC
Capacitance
Dash number 1/ 2/
Capacitance
rated
tolerance
(pF)
voltage
(± percent)
(volts)
Failure rate level (%/1,000 hours)
1.0 (M)
0.1 (P)
0.01 (R)
0.001 (S)
100
20
2,200
1564-
1524-
1484-
1444-
100
10
2,700
1565-
1525-
1485-
1445-
100
10
3,300
1566-
1526-
1486-
1446-
100
20
3,300
1567-
1527-
1487-
1447-
100
10
3,900
1568-
1528-
1488-
1448-
100
10
4,700
1569-
1529-
1489-
1449-
100
20
4,700
1570-
1530-
1490-
1450-
100
10
5,600
1571-
1531-
1491-
1451-
100
10
6,800
1572-
1532-
1492-
1452-
100
20
6,800
1573-
1533-
1493-
1453-
100
10
8,200
1574-
1534-
1494-
1454-
100
10
10,000
1575-
1535-
1495-
1455-
100
20
10,000
1576-
1536-
1496-
1456-
50
10
12,000
1577-
1537-
1497-
1457-
50
10
15,000
1578-
1538-
1498-
1458-
50
20
15,000
1579-
1539-
1499-
1459-
50
10
18,000
1580-
1540-
1500-
1460-
50
10
22,000
1581-
1541-
1501-
1461-
50
20
22,000
1582-
1542-
1502-
1462-
50
10
27,000
1583-
1543-
1503-
1463-
50
10
33,000
1584-
1544-
1504-
1464-
50
20
33,000
1585-
1545-
1505-
1465-
50
10
39,000
1586-
1546-
1506-
1466-
50
10
47,000
1587-
1547-
1507-
1467-
50
20
47,000
1588-
1548-
1508-
1468-
50
10
56,000
1589-
1549-
1509-
1469-
50
10
68,000
1590-
1550-
1510-
1470-
50
20
68,000
1591-
1551-
1511-
1471-
50
10
82,000
1592-
1552-
1512-
1472-
50
10
100,000
1593-
1553-
1513-
1473-
50
20
100,000
1594-
1554-
1514-
1474-
1/
Dash number shall include the letter "V" to indicate the optional standoff configuration
(when applicable) or "-" shall be deleted for the configuration without the standoff.
2/
For nonestablished reliability (product level C) parts, the complete PIN shall include the
letter "C" in place of "-" at the beginning of the dash number and the failure rate level "M" dash
number (e.g. M39014/01C1201 or M39014/01C1201V).
