MIL-PRF-39014/1H
Solderability: The leads shall be solderable up to .020 inch (0.51 mm) from the body egress. For styles with
standoffs, solderability shall be measured from the plane shown on figure 1.
Workmanship: Exposed copper or bare leads will be permitted to a maximum of .020 inch (0.51 mm) from the
body egress. For parts without standoffs, workmanship shall be in accordance with MIL-PRF-39014.
Part or Identifying Number (PIN): Established reliability - M39014/01-(dash number from table I). Nonestablished
reliability - M39014/01C (failure rate level M dash number from table I).
Marking: In accordance with MIL-PRF-39014, except the minimum marking as shown in the following example will
be permitted. Full marking shall be included on the package.
FRONT
BACK
M390
J--
Abbreviated PIN
"J" brand and two digit manufacturer's code or symbol 1/
0417
14/01
Date code
A
Lot code
1201
Established reliability without optional standoff
FRONT
BACK
C390
Abbreviated PIN
"J" brand and two digit manufacturer's code or symbol 1/
J--
14/01
Date code
0417
Lot code
A
1201
Nonestablished reliability without optional standoff 2/
FRONT
FRONT
C390
M390
14/01
14/01
1201V
1201V
Established reliability with optional standoff
Nonestablished reliability with optional standoff 2/
Supersession data: See table II.
______
1/ Location of manufacturer's code or symbol is optional.
2/ NOTE: The reduced marking requirement for nonestablished reliability (product level C) differs from the actual
PIN of the nonestablished reliability part in the placement of the character "C".
4
