MIL-PRF-39001/5E
TABLE I. Dimensions - Continued.
Capacitance
L
T
W,
R,
A spacing
M Dia
(pF)
Min
Max
Min
Max
max
max
± .031 (.79)
±.002 (.05)
STYLE CMR04
1 to 24, inclusive
.300 (7.62)
.360 (9.14)
.100 (2.54)
.190 (4.83)
.330 (8.38)
.125 (3.18)
.150 (3.81)
.016 (.41)
27
.300 (7.62)
.370 (9.40)
.100 (2.54)
.190 (4.83)
.330 (8.38)
.125 (3.18)
.150 (3.81)
.016 (.41)
30 to 68, inclusive
.300 (7.62)
.370 (9.40)
.100 (2.54)
.190 (4.83)
.340 (8.64)
.125 (3.18)
.150 (3.81)
.016 (.41)
75
.300 (7.62)
.370 (9.40)
.110 (2.79)
.200 (5.08)
.340 (8.64)
.125 (3.18)
.150 (3.81)
.016 (.41)
82
.300 (7.62)
.370 (9.40)
.110 (2.79)
.200 (5.08)
.350 (8.89)
.125 (3.18)
.150 (3.81)
.016 (.41)
91 and 100
.300 (7.62)
.370 (9.40)
.110 (2.79)
.200 (5.08)
.350 (8.89)
.125 (3.18)
.150 (3.81)
.016 (.41)
110 and 120
.300 (7.62)
.380 (9.65)
.110 (2.79)
.200 (5.08)
.350 (8.89)
.125 (3.18)
.150 (3.81)
.016 (.41)
130
.300 (7.62)
.380 (9.65)
.110 (2.79)
.200 (5.08)
.360 (9.14)
.125 (3.18)
.150 (3.81)
.016 (.41)
150 and 160
.300 (7.62)
.380 (9.65)
.120 (3.05)
.210 (5.33)
.360 (9.14)
.125 (3.18)
.150 (3.81)
.016 (.41)
180
.300 (7.62)
.390 (9.91)
.120 (3.05)
.210 (5.33)
.370 (9.40)
.125 (3.18)
.150 (3.81)
.016 (.41)
220 to 390, inclusive
.300 (7.62)
.390 (9.91)
.140 (3.56)
.220 (5.59)
.380 (9.65)
.125 (3.18)
.150 (3.81)
.016 (.41)
STYLE CMR05
1 to 62, inclusive
.400 (10.16)
.450 (11.43)
.090 (2.29)
.170 (4.32)
.360 (9.14)
.125 (3.18)
.225 (5.72)
.025 (.64)
68 to 82, inclusive
.400 (10.16)
.450 (11.43)
.095 (2.41)
.180 (4.57)
.360 (9.14)
.125 (3.18)
.225 (5.72)
.025 (.64)
91 and 100
.400 (10.16)
.460 (11.68)
.095 (2.41)
.180 (4.57)
.360 (9.14)
.125 (3.18)
.225 (5.72)
.025 (.64)
110 to 130, inclusive
.400 (10.16)
.460 (11.68)
.095 (2.41)
.180 (4.57)
.370 (9.40)
.125 (3.18)
.225 (5.72)
.025 (.64)
150 to 180, inclusive
.400 (10.16)
.460 (11.68)
.110 (2.79)
.190 (4.83)
.370 (9.40)
.125 (3.18)
.225 (5.72)
.025 (.64)
200
.400 (10.16)
.460 (11.68)
.110 (2.79)
.190 (4.83)
.380 (9.65)
.125 (3.18)
.225 (5.72)
.025 (.64)
220 and 240
.400 (10.16)
.460 (11.68)
.110 (2.79)
.200 (5.08)
.380 (9.65)
.125 (3.18)
.225 (5.72)
.025 (.64)
270 to 330, inclusive
.400 (10.16)
.470 (11.94)
.110 (2.79)
.210 (5.33)
.390 (9.91)
.125 (3.18)
.225 (5.72)
.025 (.64)
360 and 390
.400 (10.16)
.470 (11.94)
.120 (3.05)
.220 (5.59)
.400 (10.16)
.125 (3.18)
.225 (5.72)
.025 (.64)
STYLE CMR06
430 and 470
.550 (13.97)
.640 (16.26)
.090 (2.29)
.200 (5.08)
.510 (12.95)
.141 (3.58)
.350 (8.89)
.032 (.81)
510 to 620, inclusive
.560 (14.22)
.650 (16.51)
.090 (2.29)
.200 (5.08)
.510 (12.95)
.141 (3.58)
.350 (8.89)
.032 (.81)
680 to 910, inclusive
.560 (14.22)
.650 (16.51)
.100 (2.54)
.210 (5.33)
.510 (12.95)
.141 (3.58)
.350 (8.89)
.032 (.81)
1000 and 1100
.560 (14.22)
.650 (16.51)
.110 (2.79)
.220 (5.59)
.520 (13.21)
.141 (3.58)
.350 (8.89)
.032 (.81)
1200 and 1300
.570 (14.48)
.660 (16.76)
.110 (2.79)
.220 (5.59)
.520 (13.21)
.141 (3.58)
.350 (8.89)
.032 (.81)
1500
.570 (14.48)
.660 (16.76)
.120 (3.05)
.230 (5.84)
.520 (13.21)
.141 (3.58)
.350 (8.89)
.032 (.81)
1600
.570 (14.48)
.660 (16.76)
.120 (3.05)
.230 (5.84)
.530 (13.46)
.141 (3.58)
.350 (8.89)
.032 (.81)
1800 and 2000
.580 (14.73)
.670 (17.02)
.130 (3.30)
.240 (6.10)
.530 (13.46)
.141 (3.58)
.350 (8.89)
.032 (.81)
2200
.580 (14.73)
.670 (17.02)
.140 (3.56)
.250 (6.35)
.530 (13.46)
.141 (3.58)
.350 (8.89)
.032 (.81)
2400
.580 (14.73)
.670 (17.02)
.150 (3.81)
.260 (6.60)
.540 (13.72)
.141 (3.58)
.350 (8.89)
.032 (.81)
2700
.590 (14.99)
.680 (17.27)
.160 (4.06)
.270 (6.86)
.540 (13.72)
.141 (3.58)
.350 (8.89)
.032 (.81)
3000
.590 (14.99)
.680 (17.27)
.170 (4.32)
.280 (7.11)
.550 (13.97)
.141 (3.58)
.350 (8.89)
.032 (.81)
3300
.590 (14.99)
.680 (17.27)
.180 (4.57)
.290 (7.37)
.550 (13.97)
.141 (3.58)
.350 (8.89)
.032 (.81)
3600
.590 (14.99)
.680 (17.27)
.190 (4.83)
.300 (7.62)
.560 (14.22)
.141 (3.58)
.350 (8.89)
.032 (.81)
3900
.600 (15.24)
.690 (17.53)
.200 (5.08)
.310 (7.87)
.560 (14.22)
.141 (3.58)
.350 (8.89)
.032 (.81)
4300
.600 (15.24)
.690 (17.53)
.220 (5.59)
.330 (8.38)
.570 (14.48)
.141 (3.58)
.350 (8.89)
.032 (.81)
4700
.610 (15.49)
.700 (17.78)
.220 (5.59)
.350 (8.89)
.580 (14.73)
.141 (3.58)
.350 (8.89)
.032 (.81)
STYLE CMR07
5100
.680 (17.27)
.780 (19.81)
.150 (3.81)
.280 (7.11)
.860 (21.84)
.141 (3.58)
.425 (10.80)
.040 (1.02)
5600 and 6200
.680 (17.27)
.780 (19.81)
.150 (3.81)
.290 (7.37)
.870 (22.10)
.141 (3.58)
.425 (10.80)
.040 (1.02)
6800
.680 (17.27)
.780 (19.81)
.150 (3.81)
.300 (7.62)
.870 (22.10)
.141 (3.58)
.425 (10.80)
.040 (1.02)
7500
.690 (17.53)
.790 (20.07)
.150 (3.81)
.310 (7.87)
.880 (22.35)
.141 (3.58)
.425 (10.80)
.040 (1.02)
8200
.690 (17.53)
.790 (20.07)
.150 (3.81)
.320 (8.13)
.880 (22.35)
.141 (3.58)
.425 (10.80)
.040 (1.02)
9100
.690 (17.53)
.790 (20.07)
.150 (3.81)
.330 (8.38)
.880 (22.35)
.141 (3.58)
.425 (10.80)
.040 (1.02)
10,000
.700 (17.78)
.800 (20.32)
.200 (5.08)
.340 (8.64)
.890 (22.61)
.141 (3.58)
.425 (10.80)
.040 (1.02)
11,000
.700 (17.78)
.800 (20.32)
.200 (5.08)
.350 (8.89)
.890 (22.61)
.141 (3.58)
.425 (10.80)
.040 (1.02)
12,000
.700 (17.78)
.800 (20.32)
.200 (5.08)
.360 (9.14)
.890 (22.61)
.141 (3.58)
.425 (10.80)
.040 (1.02)
13,000
.710 (18.03 )
.810 (20.57)
.250 (6.35)
.370 (9.40)
.890 (22.61)
.141 (3.58)
.425 (10.80)
.040 (1.02)
15,000
.710 (18.03 )
.810 (20.57)
.250 (6.35)
.390 (9.91)
.900 (22.86)
.141 (3.58)
.425 (10.80)
.040 (1.02)
16,000
.720 (18.29)
.820 (20.83)
.250 (6.35)
.410 (10.41)
.900 (22.86)
.141 (3.58)
.425 (10.80)
.040 (1.02)
18,000
.720 (18.29)
.820 (20.83)
.250 (6.35)
.430 (10.92)
.910 (23.11)
.141 (3.58)
.425 (10.80)
.040 (1.02)
20,000
.730 (18.54)
.830 (21.08)
.250 (6.35)
.450 (11.43)
.920 (23.37)
.141 (3.58)
.425 (10.80)
.040 (1.02)
