MIL-PRF-39001/5E
TABLE II. Type designations - Continued.
STYLE CMR08
Type designation 1/
Capacitance value
DC rated voltage
Operating
Capacitance
(pF)
(volts)
temperature range
tolerance available
CMR08F223--D-
22000
500
O, P
F, G, J
CMR08F243--D-
24000
500
O, P
F, G, J
CMR08F273--D-
27000
500
O, P
F, G, J
CMR08F303--D-
30000
500
O, P
F, G, J
CMR08F333--D-
33000
500
O, P
F, G, J
CMR08F363--D-
36000
500
O, P
F, G, J
CMR08F393--D-
39000
500
O, P
F, G, J
CMR08F433--D-
43000
500
O, P
F, G, J
CMR08F473--D-
47000
500
O, P
F, G, J
CMR08F513--D-
51000
500
O, P
F, G, J
CMR08F563--C-
56000
300
O, P
F, G, J
CMR08F623--C-
62000
300
O, P
F, G, J
CMR08F683--C-
68000
300
O, P
F, G, J
CMR08F753--A-
75000
100
O, P
F, G, J
CMR08F823--A-
82000
100
O, P
F, G, J
CMR08F913--A-
91000
100
O, P
F, G, J
1/ Complete type designation will include additional letter symbols to indicate the following, where applicable:
Capacitance tolerance: D (±.5 F); F( ±1%); G(±2%); or J(±5%).
Operating temperature range: 0 (-55° to 125°C) or P (-55° to +150°C).
Rated voltage: Y (50v); A (100v); C (300v); or D (500v).
Product level: M (1.0%); P (0.1%); R (0.01%); S (0.001%); or C.
TABLE III. Substitutability data.
Substitute item:
Substitute for:
MIL-PRF-39001/5D
MIL-C-39001/5
CMR04C1R0D-D-
CMR04C010D-D-
CMR04C5R0D-D-
CMR04C050D-D-
CMR04C6R0D-D-
CMR04C060D-D-
CMR04C7R0D-D-
CMR04C070D-D-
CMR04C8R0D-D-
CMR04C080D-D-
CMR05C1R0D-D-
CMR05C010D-D-
CMR05C5R0D-D-
CMR05C050D-D-
CMR05C6R0D-D-
CMR05C060D-D-
CMR05C7R0D-D-
CMR05C070D-D-
CMR05C8R0D-D-
CMR05C080D-D-
12
