MIL-PRF-19978/10B
*
TABLE II. STYLE CQR12 capacitors - Continued.
Capacitance Capacitance
DC
Failure
Case dimensions
voltage
rating
tolerance
rate
Circuit 1
Circuit 3
Part number 1/
L ±.031 D +.015, L ±.031 D +.015
rating
level
-.005
-.005
µF
Volts
Inches
Inches
Inches
Inches
CQR12A-KG272-3-
1000
.0027
G, J, K
M, P, R, S
.875
.400
.812
.400
CQR12A-KG332-3-
1000
.0033
G, J, K
M, P, R, S
.875
.400
.812
.400
CQR12A-KG392-3-
1000
.0039
G, J, K
M, P, R, S
.875
.400
.812
.400
CQR12A-KG472-3-
1000
.0047
G, J, K
M, P, R, S
.875
.400
.812
.400
CQR12A-KG562-3-
1000
.0056
G, J, K
M, P, R, S
.875
.400
.812
.400
CQR12A-KG682-3-
1000
.0068
G, J, K
M, P, R, S
.875
.400
.812
.400
CQR12A-KG822-3-
1000
.0082
G, J, K
M, P, R, S
.875
.400
.812
.400
CQR12A-KG103-3-
1000
.010
G, J, K
M, P, R, S
.875
.400
.812
.400
CQR12A-KG123-3-
1000
.012
G, J, K
M, P, R, S
1.125
.400
1.062
.400
CQR12A-KG153-3-
1000
.015
G, J, K
M, P, R, S
1.125
.400
1.062
.400
CQR12A-KG183-3-
1000
.018
G, J, K
M, P, R, S
1.375
.400
1.312
.400
CQR12A-KG223-3-
1000
.022
G, J, K
M, P, R, S
1.375
.400
1.312
.400
CQR12A-KG273-3-
1000
.027
G, J, K
M, P, R, S
1.125
.562
1.062
.562
CQR12A-KG333-3-
1000
.033
G, J, K
M, P, R, S
1.125
.562
1.062
.562
CQR12A-KG393-3-
1000
.039
G, J, K
M, P, R, S
1.375
.562
1.312
.562
CQR12A-KG473-3-
1000
.047
G, J, K
M, P, R, S
1.375
.562
1.312
.562
CQR12A-KG563-3-
1000
.056
G, J, K
M, P, R, S
1.625
.562
1.562
.562
CQR12A-KG683-3-
1000
.068
G, J, K
M, P, R, S
1.625
.562
1.562
.562
CQR12A-KG823-3-
1000
.082
G, J, K
M, P, R, S
1.625
.670
1.562
.670
CQR12A-KG104-3-
1000
.10
G, J, K
M, P, R, S
1.625
.670
1.562
.670
CQR12A-KG124-3-
1000
.12
G, J, K
M, P, R, S
1.875
.670
1.812
.670
CQR12A-KG154-3-
1000
.15
G, J, K
M, P, R, S
1.875
.670
1.812
.670
CQR12A-KG184-3-
1000
.18
G, J, K
M, P, R, S
2.125
.750
2.062
.750
CQR12A-KG224-3-
1000
.22
G, J, K
M, P, R, S
2.125
.750
2.062
.750
CQR12A-KG274-3-
1000
.27
G, J, K
M, P, R, S
2.125
1.0
2.062
1.000
CQR12A-KG334-3-
1000
.33
G, J, K
M, P, R, S
2.125
1.0
2.062
1.000
CQR12A-KG394-3-
1000
.39
G, J, K
M, P, R, S
2.375
1.0
2.312
1.000
CQR12A-KG474-3-
1000
.47
G, J, K
M, P, R, S
2.375
1.0
2.312
1.000
1/
Complete part number shall include additional symbols to indicate circuit, capacitance tolerance, and failure
rate level, as applicable.
TABLE III. Multimeter equivalents of decimal inches.
Inches
mm
Inches
mm
Inches
mm
0.005
0.13
0.688
17.48
1.375
34.93
0.015
0.38
0.750
19.05
1.562
39.67
0.031
0.79
0.812
20.62
1.625
41.28
0.235
5.97
0.875
22.23
2.062
52.37
0.312
7.92
1.000
25.40
2.125
53.98
0.400
10.16
1.062
26.97
2.312
58.72
0.562
14.27
1.125
28.58
2.375
60.33
0.670
17.02
1.312
33.32
5
