MIL-PRF-19978/10B
TABLE I. Terminal-to-terminal insulation resistance.
Capacitance rating
Minimum insulation resistance
Characteristic K
At 25°C
0 to 0.6 microfarad
25,000 megohms
Greater than 0.6 microfarad
15,000 megohm-microfarads 1/
At 125°C
0 to 0.08 microfarad
250 megohms
Greater than 0.08 microfarad
20 megohm-microfarads 1/
1/
Product obtained by multiplying the capacitance in microfarads by the insulation
resistance in megohms.
TABLE II. STYLE CQR12 capacitors.
Capacitance Capacitance
Case dimensions
DC
Failure
voltage
rating
tolerance
rate
Circuit 1
Circuit 3
Part number 1/
L ±.031 D +.015, L ±.031 D +.015
rating
level
-.005
-.005
µF
Volts
Inches
Inches
Inches
Inches
CQR12A-KC392-3-
200
.0039
G, J, K
L, M, P, R, S
.750
.235
.688
.235
CQR12A-KC472-3-
200
.0047
G, J, K
L, M, P, R, S
.750
.235
.688
.235
CQR12A-KC562-3-
200
.0056
G, J, K
L, M, P, R, S
.750
.235
.688
.235
CQR12A-KC682-3-
200
.0068
G, J, K
L, M, P, R, S
.750
.235
.688
.235
CQR12A-KC183-3-
200
.018
G, J, K
L, M, P, R, S
.875
.312
.812
.312
CQR12A-KC223-3-
200
.022
G, J, K
L, M, P, R, S
.875
.312
.812
.312
CQR12A-KC273-3-
200
.027
G, J, K
L, M, P, R, S
.875
.312
.812
.312
CQR12A-KC333-3-
200
.033
G, J, K
L, M, P, R, S
.875
.312
.812
.312
CQR12A-KC393-3-
200
.039
G, J, K
L, M, P, R, S
.875
.400
.812
.400
CQR12A-KC473-3-
200
.047
G, J, K
L, M, P, R, S
.875
.400
.812
.400
CQR12A-KC563-3-
200
.056
G, J, K
L, M, P, R, S
.875
.400
.812
.400
CQR12A-KC683-3-
200
.068
G, J, K
L, M, P, R, S
.875
.400
.812
.400
CQR12A-KC823-3-
200
.082
G, J, K
L, M, P, R, S
1.125
.400
1.062
.400
CQR12A-KC104-3-
200
.10
G, J, K
L, M, P, R, S
1.125
.400
1.062
.400
CQR12A-KC124-3-
200
.12
G, J, K
L, M, P, R, S
1.375
.400
1.312
.400
CQR12A-KC154-3-
200
.15
G, J, K
L, M, P, R, S
1.375
.400
1.312
.400
CQR12A-KC184-3-
200
.18
G, J, K
L, M, P, R, S
1.125
.562
1.062
.562
CQR12A-KC224-3-
200
.22
G, J, K
L, M, P, R, S
1.125
.562
1.062
.562
CQR12A-KC274-3-
200
.27
G, J, K
L, M, P, R, S
1.375
.562
1.312
.562
CQR12A-KC334-3-
200
.33
G, J, K
L, M, P, R, S
1.375
.562
1.312
.562
CQR12A-KC394-3-
200
.39
G, J, K
L, M, P, R, S
1.625
.562
1.562
.562
CQR12A-KC474-3-
200
.47
G, J, K
L, M, P, R, S
1.625
.562
1.562
.562
CQR12A-KC564-3-
200
.56
G, J, K
L, M, P, R, S
1.625
.670
1.562
.670
CQR12A-KC684-3-
200
.68
G, J, K
L, M, P, R, S
1.625
.670
1.562
.670
CQR12A-KC824-3-
200
.82
G, J, K
L, M, P, R, S
2.125
.750
2.062
.750
CQR12A-KC105-3-
200
1.000
G, J, K
L, M, P, R, S
2.125
.750
2.062
.750
CQR12A-KE272-3-
400
.0027
G, J, K
L, M, P, R, S
.750
.235
.688
.235
CQR12A-KE332-3-
400
.0033
G, J, K
L, M, P, R, S
.750
.235
.688
.235
CQR12A-KE123-3-
400
.012
G, J, K
L, M, P, R, S
.875
.312
.812
.312
CQR12A-KE153-3-
400
.015
G, J, K
L, M, P, R, S
.875
.312
.812
.312
CQR12A-KE273-3-
400
.027
G, J, K
L, M, P, R, S
.875
.400
.812
.400
CQR12A-KE333-3-
400
.033
G, J, K
L, M, P, R, S
.875
.400
.812
.400
CQR12A-KE393-3-
400
.039
G, J, K
L, M, P, R, S
1.125
.400
1.062
.400
CQR12A-KE473-3-
400
.047
G, J, K
L, M, P, R, S
1.125
.400
1.062
.400
See footnote at end of table.
