MIL-PRF-19978/10B
TABLE II. STYLE CQR12 capacitors - Continued.
DC
Capacitance Capacitance
Failure
Case dimensions
voltage
rating
tolerance
rate
Circuit 1
Circuit 3
Part number 1/
L ±.031 D +.015, L ±.031 D +.015
level
rating
-.005
-.005
CQR12A-KE563-3-
400
.056
G, J, K
L, M, P, R, S
1.375
.400
1.312
.400
CQR12A-KE683-3-
400
.068
G, J, K
L, M, P, R, S
1.375
.400
1.312
.400
CQR12A-KE823-3-
400
.082
G, J, K
L, M, P, R, S
1.125
.562
1.062
.562
CQR12A-KE104-3-
400
.10
G, J, K
L, M, P, R, S
1.125
.562
1.062
.562
CQR12A-KE124-3-
400
.12
G, J, K
L, M, P, R, S
1.375
.562
1.312
.562
CQR12A-KE154-3-
400
.15
G, J, K
L, M, P, R, S
1.375
.562
1.312
.562
CQR12A-KE184-3-
400
.18
G, J, K
L, M, P, R, S
1.625
.562
1.562
.562
CQR12A-KE224-3-
400
.22
G, J, K
L, M, P, R, S
1.625
.562
1.562
.562
CQR12A-KE274-3-
400
.27
G, J, K
L, M, P, R, S
1.625
.670
1.562
.670
CQR12A-KE334-3-
400
.33
G, J, K
L, M, P, R, S
1.625
.670
1.562
.670
CQR12A-KE394-3-
400
.39
G, J, K
L, M, P, R, S
2.125
.750
2.062
.750
CQR12A-KE474-3-
400
.47
G, J, K
L, M, P, R, S
2.125
.750
2.062
.750
CQR12A-KF102-3-
600
.0010
G, J, K
M, P, R, S
.750
.235
.688
.235
CQR12A-KF122-3-
600
.0012
G, J, K
M, P, R, S
.750
.235
.688
.235
CQR12A-KF152-3-
600
.0015
G, J, K
M, P, R, S
.750
.235
.688
.235
CQR12A-KF182-3-
600
.0018
G, J, K
M, P, R, S
.750
.235
.688
.235
CQR12A-KF222-3-
600
.0022
G, J, K
M, P, R, S
.750
.235
.688
.235
CQR12A-KF272-3-
600
.0027
G, J, K
M, P, R, S
.875
.312
.812
.312
CQR12A-KF332-3-
600
.0033
G, J, K
M, P, R, S
.875
.312
.812
.312
CQR12A-KF392-3-
600
.0039
G, J, K
M, P, R, S
.875
.312
.812
.312
CQR12A-KF472-3-
600
.0047
G, J, K
M, P, R, S
.875
.312
.812
.312
CQR12A-KF562-3-
600
.0056
G, J, K
M, P, R, S
.875
.312
.812
.312
CQR12A-KF682-3-
600
.0068
G, J, K
M, P, R, S
.875
.312
.812
.312
CQR12A-KF822-3-
600
.0082
G, J, K
M, P, R, S
.875
.312
.812
.312
CQR12A-KF103-3-
600
.010
G, J, K
M, P, R, S
.875
.312
.812
.312
CQR12A-KF123-3-
600
.012
G, J, K
M, P, R, S
.875
.400
.812
.400
CQR12A-KF153-3-
600
.015
G, J, K
M, P, R, S
.875
.400
.812
.400
CQR12A-KF183-3-
600
.018
G, J, K
M, P, R, S
.875
.400
.812
.400
CQR12A-KF223-3-
600
.022
G, J, K
M, P, R, S
.875
.400
.812
.400
CQR12A-KF273-3-
600
.027
G, J, K
M, P, R, S
1.125
.400
1.062
.400
CQR12A-KF333-3-
600
.033
G, J, K
M, P, R, S
1.125
.400
1.062
.400
CQR12A-KF393-3-
600
.039
G, J, K
M, P, R, S
1.375
.400
1.312
.400
CQR12A-KF473-3-
600
.047
G, J, K
M, P, R, S
1.375
.400
1.312
.400
CQR12A-KF563-3-
600
.056
G, J, K
M, P, R, S
1.125
.562
1.062
.562
CQR12A-KF683-3-
600
.068
G, J, K
M, P, R, S
1.125
.562
1.062
.562
CQR12A-KF823-3-
600
.082
G, J, K
M, P, R, S
1.375
.562
1.312
.562
CQR12A-KF104-3-
600
.10
G, J, K
M, P, R, S
1.375
.562
1.312
.562
CQR12A-KF124-3-
600
.12
G, J, K
M, P, R, S
1.625
.562
1.562
.562
CQR12A-KF154-3-
600
.15
G, J, K
M, P, R, S
1.625
.562
1.562
.562
CQR12A-KF184-3-
600
.18
G, J, K
M, P, R, S
1.625
.670
1.562
.670
CQR12A-KF224-3-
600
.22
G, J, K
M, P, R, S
1.625
.670
1.562
.670
CQR12A-KF274-3-
600
.27
G, J, K
M, P, R, S
2.125
.750
2.062
.750
CQR12A-KF334-3-
600
.33
G, J, K
M, P, R, S
2.125
.750
2.062
.750
CQR12A-KF394-3-
600
.39
G, J, K
M, P, R, S
2.375
.750
2.312
.750
CQR12A-KF474-3-
600
.47
G, J, K
M, P, R, S
2.375
.750
2.312
.750
CQR12A-KG102-3-
1000
.0010
G, J, K
M, P, R, S
.875
.400
.812
.400
CQR12A-KG122-3-
1000
.0012
G, J, K
M, P, R, S
.875
.400
.812
.400
CQR12A-KG152-3-
1000
.0015
G, J, K
M, P, R, S
.875
.400
.812
.400
CQR12A-KG182-3-
1000
.0018
G, J, K
M, P, R, S
.875
.400
.812
.400
CQR12A-KG222-3-
1000
.0022
G, J, K
M, P, R, S
.875
.400
.812
.400
