TABLE I. Electrical characteristics, dimensions, and dash numbers - Continued.
Capacitance
Dimensions 1/
AC ratings (for sinusoidal operation from
Dash numbers 2/
-55°C to +100°C) 3/
value (nom)
(in inches with mm in parentheses)
(in µF)
L
D
Capacitance tolerance value (in %)
0 to .4 kHz
At 4 kHz
At 40 kHz
G
± .030 (0.76)
+.020 (0.51)
Volts Current
Volts Current Volts Current
±0.25 ±0.5 ±1.0 ±2.0 ±5.0 ±10.0
-.000
max
(in A)
(in A)
(in A)
STYLES CHR01N, CHR01P, AND CHR01R - 400 VOLTS (DC RATING)
0.15
1.375(34.93)
1.575(40.01) -085- -086- -087- -088- -089- -090-
.082
220.0
.824
40.0
1.498
0.22
.500 (12.70)
-091- -092- -093- -094- -095- -096-
.132
200.0
1.100
35.0
1.925
0.33
.562 (14.27)
-097- -098- -099- -100- -101- -102-
.198
160.0
1.322
32.0
2.645
0.47
1.875(47.83)
2.075(52.71 -103- -104- -105- -106- -107- -108-
.282
143.0
1.680
31.0
3.643
0.50
-109- -110- -111- -112- -113- -114-
.300
140.0
1.750
30.0
3.750
1.0
.750 (19.05)
-115- -116- -117- -118- -119- -120-
.600
120.0
3.000
19.0
4.750
1.5
2.375(80.33)
1.000(25.40) 2.575(65.41) -121- -122- -123- -124- -125- -126-
.899
110.0
4.120
16.0
5.993
2.0
2.375(80.33)
1.000(15.40) 2.575(64.51) -127- -128- -129- -130- -131- -132-
1.200
100.0
5.000
14.0
7.000
1/ Dimensions are bare case sizes (see figure 1).
2/ The complete dash number will include the applicable letter completing the style designator (A, B, C, D, E, F, G, H, J, K, L, M, N, P, or R)
as a prefix and the applicable FR level symbol as a suffix.
3/ For +125°C operation, linearly derate +100°C rating by 50 percent.
