MIL-C-19978-19 Capacitors, Fixed, Plastic \(Or Paper-Plastic\) Dielectric, Axial-Wire Terminal, Tubular \(Insulated\), \(Hermetically Sealed In Metal Cases\), Style Cq05

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7

MIL-C-19978/19C

Moisture resistance:

DWV:

Sleeving: In accordance with MIL-PRF-19978.

IR:

Sleeving: In accordance with MIL-PRF-19978.

Stability at low and high temperature:

Low temperature:

Test temperature: -65�C +0�, -5�C.

Capacitance change (max): -10 percent.

High temperature:

Test temperature: +125�C +5�, -0�C.

Capacitance change (max): +10 percent.

Life:

Capacitance change (max): �5 percent.

Resistance to soldering heat: In accordance with MIL-PRF-19978.

Substitution data: See table IV.

NOTE: Style CQ05 capacitors are substitutable for styles CP04 and CP05 capacitors formerly covered in

MIL-C-25/1K.

TABLE IV. Substitutability data.

From

MIL-C-25/1K

MIL-C-19978/19A

MIL-C-25/1K

MIL-C-19978/19A

(CP04 and CP05)

(CQ05)

(CP04 and CP05)

(CQ05)

CP0-A-KB273K-

CQ05A-KB273K3-

CP0-A-KC223K-

CQ05A-KC223K3-

CP0-A-KB333K-

CQ05A-KB333K3-

CP0-A-KC393K-

CQ05A-KC393K3-

CP0-A-KB823K-

CQ05A-KB823K3-

CP0-A-KC473K-

CQ05A-KC473K3-

CP0-A-KB104K-

CQ05A-KB104K3-

CP0-A-KC563K-

CQ05A-KC563K3-

CP0-A-KB124K-

CQ05A-KB124K3-

CP0-A-KC683K-

CQ05A-KC683K3-

CP0-A-KB154K-

CQ05A-KB154K3-

CP0-A-KC823K-

CQ05A-KC823K3-

CP0-A-KB184K-

CQ05A-KB184K3-

CP0-A-KC104K-

CQ05A-KC104K3-

CP0-A-KB224K-

CQ05A-KB224K3-

CP0-A-KC124K-

CQ05A-KC124K3-

CP0-A-KB274K-

CQ05A-KB274K3-

CP0-A-KC154K-

CQ05A-KC154K3-

CP0-A-KB334K-

CQ05A-KB334K3-

CP0-A-KC184K-

CQ05A-KC184K3-

CP0-A-KB394K-

CQ05A-KB394K3-

CP0-A-KC224K-

CQ05A-KC224K3-

CP0-A-KB474K-

CQ05A-KB474K3-

CP0-A-KC274K-

CQ05A-KC274K3-

CP0-A-KB564K-

CQ05A-KB564K3-

CP0-A-KC334K-

CQ05A-KC334K3-

CP0-A-KB684K-

CQ05A-KB684K3-

CP0-A-KC394K-

CQ05A-KC394K3-
