MIL-C-19978-19 Capacitors, Fixed, Plastic \(Or Paper-Plastic\) Dielectric, Axial-Wire Terminal, Tubular \(Insulated\), \(Hermetically Sealed In Metal Cases\), Style Cq05

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7


MIL-C-19978/19C
TABLE I. Style CQ05 capacitors. - Continued.
Capacitance
Part or
DC voltage
Case dimensions (inches) 2/
(µF)
Identifying
rating
Circuit 1
Circuit 3
Number (PIN) 1/
(volts)
L ±.031
L ±.031
D+.010 -.020
CQ05A-KE823K3-
400
.082
0.400
1.438
1.375
CQ05A-KE104K3-
400
.100
0.400
1.438
1.375
CQ05A-KE124K3-
400
.120
0.562
1.188
1.125
CQ05A-KE154K3-
400
.150
0.562
1.188
1.125
CQ05A-KE184K3-
400
.180
0.562
1.438
1.375
CQ05A-KE224K3-
400
.220
0.562
1.438
1.375
CQ05A-KE274K3-
400
.270
0.562
1.938
1.875
CQ05A-KE334K3-
400
.330
0.562
1.938
1.875
CQ05A-KE394K3-
400
.390
0.670
1.938
1.875
CQ05A-KE474K3-
400
.470
0.670
1.938
1.875
CQ05A-KE564K3-
400
.560
0.750
2.188
2.125
CQ05A-KE684K3-
400
.680
0.750
2.188
2.125
CQ05A-KE824K3-
400
.820
1.000
1.938
1.875
CQ05A-KE105K3-
400
1.000
1.000
1.938
1.875
CQ05A-KF102K3-
600
.001
0.235
0.812
0.750
CQ05A-KF122K3-
600
.0012
0.235
0.812
0.750
CQ05A-KF152K3-
600
.0015
0.235
0.812
0.750
CQ05A-KF182K3-
600
.0018
0.235
0.812
0.750
CQ05A-KF222K3-
600
.0022
0.235
0.812
0.750
CQ05A-KF272K3-
600
.0027
0.235
0.812
0.750
CQ05A-KF332K3-
600
.0033
0.235
0.812
0.750
CQ05A-KF392K3-
600
.0039
0.235
0.812
0.750
CQ05A-KF472K3-
600
.0047
0.235
0.812
0.750
CQ05A-KF562K3-
600
.0056
0.235
0.812
0.750
CQ05A-KF682K3-
600
.0068
0.235
0.812
0.750
CQ05A-KF822K3-
600
.0082
0.312
0.938
0.875
CQ05A-KF103K3-
600
.010
0.312
0.938
0.875
CQ05A-KF123K3-
600
.012
0.312
0.938
0.875
CQ05A-KF153K3-
600
.015
0.312
0.938
0.875
CQ05A-KF183K3-
600
.018
0.312
0.938
0.875
CQ05A-KF223K3-
600
.022
0.312
0.938
0.875
CQ05A-KF273K3-
600
.027
0.400
0.938
0.875
CQ05A-KF333K3-
600
.033
0.400
0.938
0.875
CQ05A-KF393K3-
600
.039
0.400
1.188
1.125
CQ05A-KF473K3-
600
.047
0.400
1.188
1.125
CQ05A-KF563K3-
600
.056
0.400
1.438
1.375
CQ05A-KF683K3-
600
.068
0.400
1.438
1.375
CQ05A-KF823K3-
600
.082
0.562
1.188
1.125
CQ05A-KF104K3-
600
.10
0.562
1.188
1.125
CQ05A-KF124K3-
600
.12
0.562
1.438
1.375
CQ05A-KF154K3-
600
.15
0.562
1.438
1.375
CQ05A-KF184K3-
600
.18
0.562
1.938
1.875
CQ05A-KF224K3-
600
.22
0.562
1.938
1.875
CQ05A-KF274K3-
600
.27
0.562
1.938
1.875
CQ05A-KF334K3-
600
.33
0.562
1.938
1.875
CQ05A-KF394K3-
600
.39
0.750
2.188
2.125
CQ05A-KF474K3-
600
.47
0.750
2.188
2.125
CQ05A-KF564K3-
600
.56
1.000
1.938
1.875
CQ05A-KF684K3-
600
.68
1.000
1.938
1.875
CQ05A-KG153K3-
1000
.015
0.400
0.938
0.875
See footnotes at end of table.
