MIL-C-19978/19C
TABLE I. Style CQ05 capacitors. - Continued.
Capacitance
Part or
DC voltage
Case dimensions (inches) 2/
(µF)
Identifying
rating
Circuit 1
Circuit 3
Number (PIN) 1/
(volts)
L ±.031
L ±.031
D+.010 -.020
CQ05A-KG223K3-
1000
0.022
0.400
1.188
1.125
CQ05A-KG273K3-
1000
0.027
0.400
1.438
1.375
CQ05A-KG333K3-
1000
0.033
0.400
1.438
1.375
CQ05A-KG473K3-
1000
0.047
0.562
1.188
1.125
CQ05A-KG563K3-
1000
0.056
0.562
1.438
1.375
CQ05A-KG683K3-
1000
0.068
0.562
1.438
1.375
CQ05A-KG823K3-
1000
0.082
0.562
1.688
1.625
CQ05A-KG104K3-
1000
0.10
0.562
1.688
1.625
CQ05A-KG124K3-
1000
0.12
0.670
1.688
1.625
CQ05A-KG154K3-
1000
0.15
0.670
1.688
1.625
CQ05A-KG224K3-
1000
0.22
0.750
2.188
2.125
CQ05A-KG274K3-
1000
0.27
0.750
2.688
2.625
CQ05A-KG334K3-
1000
0.33
0.750
2.688
2.625
CQ05A-KG474K3-
1000
0.47
1.000
2.188
2.125
1/ Complete PIN shall include additional symbol to indicate circuit.
2/ See table II for metric equivalents.
TABLE II. Millimeter equivalent of decimal inches.
Inches
mm
Inches
mm
Inches
mm
Inches
mm
Inches
mm
0.010
0.25
0.400
10.16
0.875
22.23
1.375
34.93
1.938
49.23
0.020
0.51
0.562
14.27
0.938
23.83
1.438
36.53
2.125
53.98
0.031
0.79
0.670
17.02
1.000
25.40
1.625
41.28
2.188
55.58
0.235
5.97
0.750
19.05
1.125
28.58
1.688
42.88
2.625
66.68
0.312
7.92
0.812
20.62
1.188
30.18
1.875
47.63
2.688
68.28
Part or Identifying Number (PIN): See table I.
Case material: Nonmagnetic (end seal may be of magnetic material).
Dielectric material: Paper and polyethelene terephthalate (K).
Circuit diagram:
3
Terminals: Axial-wire lead (see figure 1).
Rated voltage: See table I.
Rated temperature: -65° to +125°C.
Capacitance (nominal): See table I.
Capacitance tolerance: ±10 percent (symbol K).
Dissipation factor (DF) (max): 1.0 percent.
4
