MIL-C-11015/18E
Voltage-temperature limits: In accordance with MIL-C-11015 and figure 2 (for 10 pF through 1,000 pF capacitors).
Life (at elevated ambient temperature): In accordance with MIL-C-11015.
Test potential - 200 percent of rated voltage.
IR -
1,000 megohms, min or 10 megohm-microfarads, min, whichever is less (at 125 C), and not less than
10 percent of initial requirement (at 25 C).
C - Shall not exceed 20 percent from initial measured value.
DF - 2.5 percent, max (at 25 C).
Marking: In accordance with MIL-C-11015, and as shown in figure 1.
Changes from previous issue: Marginal notations are not used in this revision to identify changes with respect to
the previous issue due to the extent of the changes.
Supersession data: Items having a "CW" voltage-temperature limit formerly covered by Rev. A, and earlier issues,
of this specification sheet are superseded as indicated in table II.
TABLE II. Cross-reference of substitute items.
Superseded
Recommended
Superseded
Recommended
Item 1/
substitute
item 1/
substitute
item 1/
item 1/
CK05CW100-
CK05BX100-
CK05CW121K
CK05BX121K
CK05CW120K
CK05BX120K
CK05CW151-
CK05BX151-
CK05CW150-
CK05BX150-
CK05CW181K
CK05BX181K
CK05CW180K
CK05BX180K
CK05CW221-
CK05BX221-
CK05CW220-
CK05BX220-
CK05CW271K
CK05BX271K
CK05CW270K
CK05BX270K
CK05CW331-
CK05BX331-
CK05CW330-
CK05BX330-
CK05CW391K
CK05BX391K
CK05CW390K
CK05BX390K
CK05CW471-
CK05BX471-
CK05CW470-
CK05BX470-
CK05CW561K
CK05BX561K
CK05CW560K
CK05BX560K
CK05CW681-
CK05BX681-
CK05CW680-
CK05BX680-
CK05CW821K
CK05BX821K
CK05CW820K
CK05BX820K
CK05AW102-
CK05BX102-
CK05CW101-
CK05BX101-
1/ Where required, the PIN will include comparable capacitance tolerance symbol.
Inactive styles: For new design units of MIL-PRF-39014/1 should be used as listed in table III. Although table III
lists only the highest failure rate level, lower failure rate levels may be considered. For substitutability of the
inactivated styles, established reliability capacitors in MIL-PRF-39014/1 of the same capacitance value, tolerance,
rated voltage and temperature coefficient can be used regardless of the failure rate designation.
5
