MIL-C-11015/18E
TABLE I. Style CK05 characteristics.
Rated temperature
PIN 1/
Rated
and voltage-
Capacitance
Capacitance
voltage
temperature limits
tolerance
volts, dc
pF
CK05BX100-
200
BX
10
K, M
CK05BX120K
200
BX
12
K
CK05BX150-
200
BX
15
K, M
CK05BX180K
200
BX
18
K
CK05BX220-
200
BX
22
K, M
CK05BX270K
200
BX
27
K
CK05BX330-
200
BX
33
K, M
CK05BX390K
200
BX
39
K
CK05BX470-
200
BX
47
K, M
CK05BX560K
200
BX
56
K
CK05BX680-
200
BX
68
K, M
CK05BX820K
200
BX
82
K
CK05BX101-
200
BX
100
K, M
CK05BX121K
200
BX
120
K
CK05BX151-
200
BX
150
K, M
CK05BX181K
200
BX
180
K
CK05BX221-
200
BX
220
K, M
CK05BX271K
200
BX
270
K
CK05BX331-
200
BX
330
K, M
CK05BX391K
200
BX
390
K
CK05BX471-
200
BX
470
K, M
CK05BX561K
200
BX
560
K
CK05BX681-
200
BX
680
K, M
CK05BX821K
200
BX
820
K
CK05BX102-
200
BX
1,000
K, M
CK05BX122K
100
BX
1,200
K
CK05BX152-
100
BX
1,500
K, M
CK05BX182K
100
BX
1,800
K
CK05BX222-
100
BX
2,200
K, M
CK05BX272K
100
BX
2,700
K
CK05BX332-
100
BX
3,300
K, M
CK05BX392K
100
BX
3,900
K
CK05BX472-
100
BX
4,700
K, M
CK05BX562K
100
BX
5,600
K
CK05BX682-
100
BX
6,800
K, M
CK05BX822K
100
BX
8,200
K
CK05BX103-
100
BX
10,000
K, M
CK05BX123K
50
BX
12,000
K
CK05BX153-
50
BX
15,000
K, M
CK05BX183K
50
BX
18,000
K
CK05BX223-
50
BX
22,000
K, M
CK05BX273K
50
BX
27,000
K
CK05BX333-
50
BX
33,000
K, M
CK05BX393K
50
BX
39,000
K
CK05BX473-
50
BX
47,000
K, M
CK05BX563K
50
BX
56,000
K
CK05BX683-
50
BX
68,000
K, M
CK05BX823K
50
BX
82,000
K
CK05BX104-
50
BX
100,000
K, M
1/ Where applicable, the complete PIN will include an additional symbol to indicate capacitance tolerance.
