MIL-PRF-55681/5E
TABLE I. Styles CDR21, CDR22, CDR23, CDR24, and CDR25 capacitor characteristics - Continued.
Capacitance
Rated temperature and
Capacitance
tolerance
voltage-temperature
PIN 1/
Rated voltage
limits
pF
V dc
CDR2-B-112A - - -
1,100
F,G,J,K,M
BP
50
CDR2-B-122A - - -
1,200
F,G,J,K,M
BP
50
CDR2-B-132A - - -
1,300
F,G,J,K,M
BP
50
CDR2-B-152A - - -
1,500
F,G,J,K,M
BP
50
CDR2-B-162A - - -
1,600
F,G,J,K,M
BP
50
CDR2-B-182A - - -
1,800
F,G,J,K,M
BP
50
CDR2-B-202A - - -
2,000
F,G,J,K,M
BP
50
CDR2-B-222A - - -
2,200
F,G,J,K,M
BP
50
CDR2-B-242A - - -
2,400
F,G,J,K,M
BP
50
CDR2-B-272A - - -
2,700
F,G,J,K,M
BP
50
CDR2-B-302A - - -
3,000
F,G,J,K,M
BP
50
CDR2-B-332A - - -
3,300
F,G,J,K,M
BP
50
CDR2-B-362A - - -
3,600
F,G,J,K,M
BP
50
CDR2-B-392A - - -
3,900
F,G,J,K,M
BP
50
CDR2-B-432A - - -
4,300
F,G,J,K,M
BP
50
CDR2-B-472A - - -
4,700
F,G,J,K,M
BP
50
CDR2-B-502A - - -
5,000
F,G,J,K,M
BP
50
CDR2-B-512A - - -
5,100
F,G,J,K,M
BP
50
1/ Complete PIN will include additional symbols to indicate style, voltage-temperature limits, capacitance tolerance
(where applicable), termination finish ("T" for styles CDR21, CDR22, and CDR24, and "S" for styles CDR23 and
CDR25), and product level.
Changes from previous issue. The margins of this specification are marked with vertical lines to indicate where
changes from the previous issue were made. This was done as a convenience only and the Government assumes
no liability whatsoever for any inaccuracies in these notations. Bidders and contractors are cautioned to evaluate the
requirements of this document based on the entire content irrespective of the marginal notations and relationship to
the last previous issue.
Custodians:
Preparing activity:
Army - CR
Army - CR
Navy - EC
Air Force - 11
Agent:
DLA - CC
DLA CC
Review activities:
Navy - AS, MC, OS, SH
(Project 5910-2006-050)
Air Force - 19, 99
NOTE: The activities listed above were interested in this document as of the date of this document. Since
organizations and responsibilities can change, you should verify the currency of the information above using the
ASSIST Online database at https://assist.daps.dla.mil.
