MIL-PRF-55681/5E
L1
L
2 PLS
.016 NOM DIA
W
.500 MIN
T
Style CDR25
Inches
mm
Inches mm
.001
0.03
.030
0.76
.004
0.10
.093
2.36
.005
0.13
.100
2.54
.015
0.38
.110
2.79
.016
0.41
.135
3.43
.020
0.51
.250
6.35
.025
0.64
.500 12.70
Dimensions
Style
L
W
T
L1
F
Min
Max
Max 1/
Max
2/
.110 ±.015
.135 ±.015
---
.020
.100
.030
CDR21
.110 ±.015
.135 ±.015
---
.020
.100
.030
CDR22
.110 ±.015
.135 ±.015
.020
.020
.100
.030
CDR23
.020
.020
.100
.030
CDR24
.110 ±.015
.135 ±.015
---
.020
.100
.030
CDR25
.110 ±.015
.135 ±.015
1/ Solder buildup over each lead.
2/ Solder fill.
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
FIGURE 1. Dimensions and configuration - Continued.
3
